To document immunity against burst transient from electrical phenomena, the following immunity tests have been made on a system
consisting of:
A drive (with options if relevant).
l
A shielded control cable.
l
A control box with potentiometer, motor cable, and motor.
l
The tests were performed in accordance with the following basic standards:
EN 61000-4-2 (IEC 61000-4-2) Electrostatic discharges (ESD): Simulation of electrostatic discharges from human beings.
l
EN 61000-4-3 (IEC 61000-4-3) Radiated immunity: Amplitude modulated simulation of the effects of radar and radio
l
communication equipment and mobile communications equipment.
EN 61000-4-4 (IEC 61000-4-4) Burst transients: Simulation of interference caused by switching a contactor, relay, or similar devices.
l
EN 61000-4-5 (IEC 61000-4-5) Surge transients: Simulation of transients caused by, for example, lightning that strikes near
l
installations.
EN 61000-4-6 (IEC 61000-4-6) Conducted immunity: Simulation of the effect from radio-transmission equipment joined by
l
connection cables.
The immunity requirements should follow product standard IEC 61800-3. See
Table 36: EMC Immunity
Product standard
Test
Acceptance criterion
Mains cable
Motor cable
Brake cable
Load sharing cable
Relay cable
Control cable
Standard/fieldbus cable
Control panel cable
Enclosure
Definitions
CD: Contact discharge
AD: Air discharge
50 | Danfoss A/S © 2024.08
61800-3
ESD Radiated Burst
immunity
B A B
– – 2 kV CN
– – 2 kV CCC
– – 2 kV CCC
– – 2 kV CCC
– – 2 kV CCC
– – Length >2 m (6.6 ft)
1 kV CCC
– – Length >2 m (6.6 ft)
1 kV CCC
– – Length >2 m (6.6 ft)
1 kV CCC
4 kV 10 V/m –
CD
8 kV
AD
DM: Differential mode
CM: Common mode
Table 36 for details.
Surge
B
1 kV/2 Ω DM
2 kV/12 Ω CM
–
–
–
–
Unshielded: 1 kV/42
Ω CM
Unshielded: 1 kV/42
Ω CM
–
–
CN: Direct injection through coupling network
CCC: Injection through capacitive coupling
clamp
AJ402315027937en-000401 / 130R1239
Specifications
Conducted
immunity
A
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
–
