Danfoss iC2-Micro Series Design Manual page 80

Design Guide | iC2-Micro Frequency Converters
1
2
3
4
L1
5
L2
L3
6
PE
Figure 39: Example of Proper EMC Installation
1 Programmable logic controller (PLC)
3 Control cables
5 Mains supply
7 Output contactor, and so on.
9
Cable insulation stripped
11 Motor cable
80 | Danfoss A/S © 2024.08
4
4
2
2
Minimum 16 mm (6 AWG) equalizing cable
4 Minimum 200 mm (7.9 in) between control cables, motor
cables, and mains cables
6 Reinforced protective earth
8 Grounding rail
10
All cable entries in one side of panel
12 Connecting to motor (3 phases and protective earth)
Electrical Installation Considerations
7
8
9
10
11
12
