Design Guide | iC2-Micro Frequency Converters
Table 19: Mains Supply
(continued)
Function
Displacement power factor
Switching on input supply from a dis-
charged drive
Environment
4.2.3

Motor Output and Motor Data

Table 20: Motor Output (U, V, W)
Function
Output voltage
(1)
Output frequency
Frequency resolution
Switching on output
1) Dependent on voltage, current, and control mode.

Torque Characteristics

4.2.4
Table 21: Torque Characteristics
Function
Overload torque
Overload torque at start
Torque rise time (VVC+)

Control I/O

4.2.5

Control I/O Overview

4.2.5.1
This chapter covers the general specifications of the control I/O.
The standard configuration for iC2-Micro Frequency Converters is:
4 digital inputs.
l
1 digital I/O (Select ether digital input or output).
l
2 analog inputs (voltage or current).
l
1 analog output (current).
l
1 relay outputs (NC/NO).
l
24 V and 10 V reference for digital and analog I/O.
l
40 | Danfoss A/S © 2024.08
Data
near unity (>0.98)
MA01a–MA03a: Maximum 2 times/min
MA04a–MA05a: Maximum 1 time/min
Overvoltage category III/pollution degree 2
Data
0–100 % of supply voltage
Induction motor
• 0–200 Hz (VVC+ mode)
• 0–500 Hz (U/f mode)
PM motor
• 0–400 Hz (VVC+ mode)
0.001 Hz
±0.003 Hz
Data
150% for 60 s every 10 min
200% for 1 s
50 ms
Specifications
AJ402315027937en-000401 / 130R1239
