Design Guide | iC2-Micro Frequency Converters
Table 65: iC2-Micro Frequency Converters- Mains: 3x200–240 V AC, 40% Duty Cycle
Power P R
m (HO) min
rating
3-phase [kW [Ω]
200– (hp)]
240 V
07A8 1.5 (2.0) 53
11A0 2.2 (3.0) 35
15A2 3.7 (5.0) 20
24A2 5.5 (7.5) 14
31A0 7.5 (10) 9
46A2 11 (15) 7
1) All cabling must comply with national and local regulations on cable cross-sections and ambient temperature.
102 | Danfoss A/S © 2024.08
R R P
br. nom rec br avg
[Ω] [Ω] [kW (hp)]
62.70 59 0.541 (0.725)
42.06 39 0.807 (1.082)
24.47 23 1.386 (1.859)
17.28 16 2.070 (2.776)
12.56 11 2.847 (3.818)
8.49 8 4.215 (5.652)
Code Period Cable cross-
number
section
175Uxxxx [s]
[mm
3302 120 1.5 (16)
3303 120 1.5 (16)
3305 120 1.5 (16)
3306 120 1.5 (16)
3307 120 2.5 (14)
3176 120 4 (12)
How to Order
Thermal Maximum
relay brake
(1)
torque
with
resistor
[A] [%]
2
(AWG)]
2.7 143
4.2 140
6.8 145
10.4 144
14.7 145
23 141
