The dimensions apply to both solid and stranded cables. Drives are designed for use of 70 °C (158 °F) rated copper cables. If nothing else
is stated, the ambient temperature of the drive matches the cable rating. Aluminum cables can be used from 35 mm
connections must be secured by removing the oxide layer and applying joint compound.
Using a cable with the maximum allowed cross-section requires more effort during the installation.
Table 33: Power Cable Sizing
Enclosure Terminal
size
MA01c Mains, motor, and DC
connection
Customer relay
MA02c Mains, motor, and DC
connection
Customer relay
MA01a Mains and motor
DC connection
Customer relay
MA02a Mains and motor
(1)
Brake and DC con-
nection
Customer relay
MA03a Mains and motor
Brake and DC con-
nection
Customer relay
MA04a Mains
Motor, brake, and DC
connection
Customer relay
MA05a Mains
Motor, brake, and DC
connection
Customer relay
1) For MA02a, only 3x200–240 V and 3x380–480 V drives have brake function.
Danfoss A/S © 2024.08
NOTICE
Torque
2
Cross-section [mm
[Nm (lb-
(AWG)]
in)]
0.5–4.0 (24–10) 0.7 (6.2)
0.5–2.5 (24–12) 0.5 (4.4)
0.5–4.0 (24–10) 0.7 (6.2)
0.5–2.5 (24–12) 0.5 (4.4)
0.5–4.0 (24–10) 0.7 (6.2)
2.1–5.3 (14–10) –
0.5–2.5 (24–12) 0.5 (4.4)
0.5–4.0 (24–10) 0.7 (6.2)
2.1–5.3 (14–10) –
0.5–2.5 (24–12) 0.5 (4.4)
0.5–4.0 (24–10) 0.7 (6.2)
2.1–5.3 (14–10) –
0.5–2.5 (24–12) 0.5 (4.4)
0.5–16 (22–6) 1.2 (10.6)
0.5–16 (20–6) 1.2 (10.6)
0.5–2.5 (24–12) 0.5 (4.4)
0.5–16 (22–6) 1.2 (10.6)
0.5–16 (20–6) 1.2 (10.6)
0.5–2.5 (24–12) 0.5 (4.4)
Stripping length Connector type
[mm (in)]
7–9 (0.28–0.35) Terminal block
6–7 (0.24–0.28) Terminal block
7–9 (0.28–0.35) Terminal block
6–7 (0.24–0.28) Terminal block
7–9 (0.28–0.35) Terminal block
6–7 (0.24–0.28) Straight receptacles
6–7 (0.24–0.28) Terminal block
7–9 (0.28–0.35) Terminal block
6–7 (0.24–0.28) Straight receptacles
6–7 (0.24–0.28) Terminal block
7–9 (0.28–0.35) Terminal block
6–7 (0.24–0.28) Straight receptacles
6–7 (0.24–0.28) Terminal block
12–13 (0.47–0.51) Terminal block
12–15 (0.47–0.59) Terminal block
6–7 (0.24–0.28) Terminal block
12–13 (0.47–0.51) Terminal block
12–15 (0.47–0.59) Terminal block
6–7 (0.24–0.28) Terminal block
AJ402315027937en-000401 / 130R1239 |
Specifications
2
onwards. Proper
Screw/
lug type
Slot
Slot
Slot
Slot
Slot
–
Slot
Slot
–
Slot
Slot
–
Slot
Slot
Slot
Slot
Slot
Slot
Slot
