Design Guide | iC2-Micro Frequency Converters
Table 23: Digital and Pulse Output
Function
Terminal number
Digital output (24 V)
1) T15 is selectable for either digital input, digital output, or pulse output. The default setting is digital input.
4.2.5.4

Analog Input

Control inputs and outputs are PELV galvanically isolated from supply voltage and other high-voltage terminals, unless otherwise
specified.
Table 24: Analog Input
Function
Terminal number
Input mode
Voltage mode
Current mode
Resolution
Accuracy
Bandwidth
1) The selection is made in the software. For more information, refer to the application guide.

Analog Output

4.2.5.5
Control inputs and outputs are PELV galvanically isolated from supply voltage and other high-voltage terminals, unless otherwise
specified.
42 | Danfoss A/S © 2024.08
Voltage level
Maximum output load (sink/source)
Frequency range - Pulse output
Maximum load
Maximum capacitive load at maximum
frequency
Pulse output accuracy
Resolution of pulse output
Data
T33 and T34
Current or Voltage
• Voltage range: 0–10 V (scalable)
• Input impedance: 10 kΩ
• Maximum voltage: +20 V/-12 V
• Current range: 0/4-20 mA (scalable)
• Input impedance: 200 Ω
• Maximum current: 30 mA
0.1% of full scale
1% of full scale
100 Hz
Data
(1)
T15
0/24 V
40 mA
4 Hz–32 kHz
1 kΩ
10 nF
0.1% of full scale
10 bit
(1)
AJ402315027937en-000401 / 130R1239
Specifications
