Control Terminal Types - Danfoss iC2-Micro Series Design Manual

Design Guide | iC2-Micro Frequency Converters
L1/L L2
200–240 V AC /
3
L1/L L2
1 100–120 V AC /
Figure 48: Single-phase and 3-phase Wire Connections
2.
Depending on the configuration of the equipment, connect the input power to the mains input terminals or the input
disconnect.
3.
Ground the cable in accordance with the grounding instructions, see
7.10.4

Control Terminal Types

1
Figure 49: Control Terminal Numbers and Locations
1 Control I/O terminals
3 Relay
Table 55: Terminal Descriptions
Terminal Parameter
Digital I/O, pulse I/O
12 –
13
Parameter P 9.4.1.2 Terminal 13
Digital Input
14
Parameter P 9.4.1.3 Terminal 14
Digital Input
92 | Danfoss A/S © 2024.08
L3/N
3 380–480 V AC
L3/N
1 200–240 V AC
2
Default setting
+24 V DC
[8] Start
[10] Reversing
7.4.2 Power Cables and
2 Serial communication
Description
24 V DC supply voltage. Maximum output current is
100 mA.
Digital input.
Digital input.
Electrical Installation Considerations
Grounding.
3
AJ402315027937en-000401 / 130R1239
