General Technical Data; Protection And Features; Grid Side - Danfoss iC2-Micro Series Design Manual

Design Guide | iC2-Micro Frequency Converters
Table 18: Mains Supply 3x380–480 V AC, MA03a–MA05a
Continuous (3x440–480 V) [A]
Intermittent (3x440–480 V) [A]
Maximum cable size
2
(Mains, motor) [mm /AWG]
Maximum input current
Continuous (3x380–440 V) [A]
Intermittent (3x380–440 V) [A]
Continuous (3x440–480 V) [A]
Intermittent (3x440–480 V) [A]
EMC filter type
Environment
(1)
Power loss [W]
(1)
Efficiency [%]
1) The value is measured at 100% rated torque-producing current and 90% rated motor stator frequency according to IEC 61800-9-2 and EN 50598-2.

General Technical Data

4.2

Protection and Features

4.2.1
Electronic motor thermal protection against overload.
l
Temperature monitoring of the heat sink ensures that the drive trips if there is overtemperature.
l
The drive is protected against short circuits between motor terminals U, V, W.
l
When a motor phase is missing, the drive trips and issues a fault.
l
When a mains phase is missing, the drive trips or issues a warning (depending on the load).
l
Monitoring of the DC-link voltage ensures that the drive trips when the DC-link voltage is too low or too high.
l
The drive is protected against ground faults on motor terminals U, V, W.
l

Grid Side

4.2.2
Table 19: Mains Supply
Function
Supply voltage
Grid types
Supply frequency
Maximum temporary imbalance between
mains phases
Danfoss A/S © 2024.08
(continued)
11 14
16.5 21.3
4/10
19.2 24.8
27.4 36.3
16.6 21.4
23.6 30.1
C2/C4
104 127
98.3 98.4
Data
1x100–120 V AC ±10%, -15% at reduced torque performance, depending on motor type.
1x200–240 V AC ±10%, -15% at reduced torque performance, depending on motor type.
3x380–480 V AC ±10%, -15% at reduced torque performance, depending on motor type.
TN, TT, IT, Grounded Delta grids. For more information, see
on the parameters related to grid types, refer to the application guide.
50/60 Hz ±5%
3% of rated voltage, depending on grid impedance.
21 27
31.5 40.5
16/6
33 42
47.5 60
29 36
41 52
213 285
98.2 98.3
AJ402315027937en-000401 / 130R1239 |
Specifications
34 40
51 60
34.7 41.2
49 57.6
31.5 37.5
44 53
358 466
98.2 98
7.3.1 Grid Types. For details
39
