Danfoss iC2-Micro Series Design Manual page 90

Design Guide | iC2-Micro Frequency Converters
1
2
Figure 46: Mains, Motor, and Grounding Connection for Single-phase Units (Taking MA02c as an Example)
1 Mains
3 Motor
For MA01c and MA02c drives, grounding point A supports 10 mm
type is JST copper tubular lug TUB-4.
For MA01c and MA02c drives, decoupling plates are needed if 3 grounding terminals are used.
90 | Danfoss A/S © 2024.08
3
4
2 Grounding point A
4 Grounding point B
NOTICE
2
(7 AWG) cable via a cable shoe, the recommended cable shoe
NOTICE
Electrical Installation Considerations
AJ402315027937en-000401 / 130R1239
