5.3 General Technical Data

Supply voltage VLT 2803-2840 220-240 V (N, L1)
Supply voltage VLT 2803-2840 200-240 V
Supply voltage VLT 2805-2882 380-480 V
Supply voltage VLT 2805-2840 (R5)
Supply frequency
Max. imbalance on supply voltage
True power factor (λ)
Displacement power factor (cos φ)
Number of connections at supply input L1, L2, L3
Max. short-circuit value
See chapter 5.1 Special Conditions for further information.
Output data (U, V, W)
Output voltage
Output frequency
Rated motor voltage, 200-240 V units
Rated motor voltage, 380-480 V units
Rated motor frequency
Switching on output
Ramp times
Torque characteristics
Starting torque (parameter 101 Torque characteristic=Constant torque)
Starting torque (parameter 101 Torque characteristics=Variable torque)
Starting torque (parameter 119 High starting torque )
Overload torque (parameter 101 Torque characteristic=Constant torque)
Overload torque (parameter 101 Torque characteristic=Variable torque)
Percentage relates to frequency converter's nominal current.
1) VLT 2822 PD2/2840 PD2 1x220 V only 110% in 1 min
Control card, digital inputs
Number of programmable digital inputs
Terminal number
Voltage level
Voltage level, logic '0'
Voltage level, logic '1'
Maximum voltage on input
Input resistance, R (terminals 18, 19, 27, 29)
i
Input resistance, R (terminal 33)
i
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. See
chapter 5.1.1 Galvanic Isolation (PELV) for further information.
