TEG-S40SX
Gigabit Ethernet Switch
User's Guide
First Edition (Feb., 2000)
Printed In Taiwan
RECYCLABLE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEG-S40SX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRENDnet TEG-S40SX

Summary of Contents for TRENDnet TEG-S40SX

  • Page 1 TEG-S40SX Gigabit Ethernet Switch User’s Guide First Edition (Feb., 2000) Printed In Taiwan RECYCLABLE...
  • Page 2 FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 3: Table Of Contents

    ABLE OF ONTENTS ABOUT THIS GUIDE ................V ......................ERMS ’ ..............VERVIEW OF THIS UIDE INTRODUCTION..................1 ............... 1 IGABIT THERNET ECHNOLOGY ................2 WITCHING ECHNOLOGY ..................... 3 EATURES Ports......................4 Performance features................4 Management ..................... 4 UNPACKING AND SETUP..............6 ....................
  • Page 4 WITCH ..............30 ONSOLE SAGE ONVENTIONS ..........31 IRST ONNECTING WITCH Steps to Create Administrator or Normal User Access ......32 Administrator and Normal User Privileges..........33 Save Configuration ................. 34 ......34 OGIN WITCH ONSOLE EGISTERED SERS Add/Modify User Account............... 35 View/Delete User Account ..............
  • Page 5 Configuration..................75 Bridge ..................... 87 Monitor ....................95 User....................... 102 Help....................... 103 TECHNICAL SPECIFICATIONS............104 INDEX..................... 106...

  • Page 7: About This Guide

    For simplicity, this documentation uses the terms “Switch” (first letter upper case) to refer to the TEG-S40SX Gigabit Ethernet Switch, and “switch” (first letter lower case) to refer to all Ethernet switches, including the TEG-S40SX. Overview of this User’s Guide ♦...
  • Page 8 Management via the RS-232 DCE console port and other aspects about how to manage the Switch. ♦ Chapter 6, Using the Console Interface. Tells how to use the built-in console interface to change, set, and monitor Switch performance and security.

  • Page 9: Introduction

    Gigabit Ethernet Switch User’s Guide NTRODUCTION This section describes the features of the TEG-S40SX, as well as giving some background information about Gigabit Ethernet and switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing...

  • Page 10: Switching Technology

    Likewise, since data transfers occur 10 times faster than Fast Ethernet, servers outfitted with Gigabit Ethernet NIC’s are able to perform 10 times the number of operations in the same amount of time. In addition, the phenomenal bandwidth delivered by Gigabit Ethernet is the most cost-effective method to take advantage of today and tomorrow’s rapidly improving switching and routing...

  • Page 11: Features

    For Fast Ethernet or Gigabit Ethernet networks, a switch is an effective way of eliminating problems of chaining hubs beyond the “two-repeater limit.” A switch can be used to split parts of the network into different collision domains, for example, making it possible to expand your Fast Ethernet network beyond the 205 meter network diameter limit for 100BASE-TX networks.

  • Page 12: Ports

    ♦ Full duplex to allow two communicating stations to transmit and receive at the same time. ♦ Data forwarding rate 1,488,100 pps per port at 100% of wire- speed for 1000Mbps speed. ♦ Data filtering rate eliminates all error packets, runts, etc. at 1,488,100 pps per port at 100% of wire-speed for 1000Mbps speed.
  • Page 13 ♦ Fully configurable either in-band or out-of-band control via SNMP based software. ♦ Flash memory for software upgrade. This can be done in- band via BOOTP/TFTP. Out-of-band console can also initiate a download request.

  • Page 14: Unpacking And Setup

    ♦ Four rubber feet with adhesive backing ♦ One AC power cord ♦ This user’s guide with Registration Card ♦ Diskette containing management software If any item is found missing or damaged, please contact your local reseller for replacement. Unpacking and Setup...

  • Page 15: Setup

    The setup of the Switch can be performed using the following steps: ♦ The surface must support at least 3 kg. ♦ The power outlet should be within 1.82 meters (6 feet) of the device. ♦ Visually inspect the power cord and see that it is secured fully to the AC power connector.

  • Page 16: Rack Installation

    Rack Installation The TEG-S40SX can be mounted in an EIA standard size, 19-inch rack, which can be placed in a wiring closet with other equipment. To install, attach the mounting brackets on the switch’s front panel (one on each side) and secure them with the screws provided.

  • Page 17: Power On

    Power on The TEG-S40SX Switch can be used with AC power sources 100 - 240 VAC, 50 - 60 Hz. The Switch’s power supply will adjust to the local power source automatically and may be turned on without having any or all LAN segment cables connected.

  • Page 18: Power Failure

    ♦ The Power LED indicator will light while the Switch loads onboard software and blinks when performing a self-test. ♦ The Console LED indicator will remain ON if there is a connection at the RS-232 port, otherwise this LED indicator is OFF.

  • Page 19: Identifying External Components

    This chapter describes the front panel, rear panel and LED indicators of the Switch Front Panel The front panel of the Switch consists of 4 1000BASE-SX multi- mode fiber ports, an RS-232 communication port, and LED indicators. Figure 3-1. Front panel view of the TEG-S40SX Switch ♦...

  • Page 20: Rear Panel

    Switch and status of the network. A description of these LED indicators follows (see LED Indicators). Rear Panel The rear panel of the Switch consists of an AC power connector. The following shows the rear panel of the Switch. Figure 3-2. Rear panel view of the TEG-S40SX ♦...

  • Page 21: Led Indicators

    Figure 3-3. Right side panel view of the TEG-S40SX ♦ System Fans These fans are used to dissipate heat. The sides of the system also provide heat vents to serve the same purpose. Do not block these openings, and leave adequate space at the rear and sides of the Switch for proper ventilation.
  • Page 22 Otherwise, it is OFF. ♦ Link/Act. These LED indicators are lighted up when there is a secure connection (or link) to a device at any of the ports. The LED indicators blink whenever there is reception or transmission (i.e.

  • Page 23: Connecting The Switch

    This chapter describes how to connect the TEG-S40SX to your Gigabit Ethernet network. PC to Switch A PC can be connected to the Switch via a fiber optic cable. The PC should be connected to any of the four ports (1x - 4x) of the TEG- S40SX.

  • Page 24: Switch To Switch (Other Devices)

    Gigabit Ethernet Switch User’s Guide making a proper connection, check the PC’s LAN card, the cable, Switch conditions, and connections. The following are LED indicator possibilities for a PC to Switch connection: ♦ The Link/Act LED indicator lights up upon hookup.

  • Page 25: Switch Management

    Out-of-Band Management for the Switch is accomplished through a locally connected management terminal to the RS-232 console port. Through this port, a user can set up, monitor, or change the configuration of the Switch. The Spanning Tree Algorithm (STA) provides the capability for the Switch to operate properly with other Bridges in a SNMP network supporting the STA.

  • Page 26: Console Port (Rs-232 Dce)

    Switch IP Address to meet the specification of your networking address scheme. In addition, you can also set in the Switch an IP Address for a gateway or a router. It is useful when the network management station is not located on the same network as the Switch, making it necessary for the Switch to go through a gateway or router to reach the network manager.

  • Page 27: Traps

    Gigabit Ethernet Switch User’s Guide For security, you can set in the Switch a list of IP Addresses of the network managers that you allow to manage the Switch. You can also change the default Community Name in the Switch and set access rights of these Community Names.

  • Page 28: Mibs

    ♦ New Root This trap indicates that the Switch has become the new root of the Spanning Tree, the trap is sent by a bridge soon after its election as the new root. This implies that upon expiration of the Topology Change Timer the new root trap is sent out immediately after the Switch’s selection...

  • Page 29: Packet Forwarding

    Switch, a diskette listing the Switch’s propriety enterprise MIBs can be obtained by request. If your software provides functions to browse or modify MIBs, you can also get the MIB values and change them (if the MIBs’ attributes permit the write operation).

  • Page 30: Aging Time

    Entries, which make up the auto-learned-node address, are aged out of the address table according to the Aging Time that you set. The Aging Time can be from 1 to 99 minutes. A very long Aging Time can result with the out-of-date Dynamic Entries that may cause incorrect packet filtering/forwarding decisions.

  • Page 31: Spanning Tree Algorithm

    STA Operation Levels STA operates on two levels: the bridge level and the port level. On the bridge level, STA calculates the Bridge Identifier for each Switch, then sets the Root Bridge and the Designated Bridges. On the port level, STA sets the Root Port and Designated Ports.
  • Page 32 ♦ Bridge Identifier This is the combination of the Bridge Priority (a parameter that you can set) and the MAC address of the switch. Example: 4 00 80 C8 00 01 00, where 4 is the Bridge Priority. A lower Bridge Identifier results in a higher priority for the switch, and thus increases it probably of being selected as the Root Bridge.

  • Page 33: User-Changeable Parameters

    ♦ Bridge Max. Age The Max. Age can be from 6 to 40 seconds. At the end of the Max. Age, if a BPDU has still not been received from the Root Bridge, your Switch will start sending its own BPDU to all other Switches for permission to become the Root Bridge.

  • Page 34: Illustration Of Sta

    STA calculation of the most current Bridge and Port settings. Now, if Bridge 1 broadcasts a packet to Bridge 3, then Bridge 3 will broadcast it to Bridge 2 and the broadcast will end there.
  • Page 35 Gigabit Ethernet Switch User’s Guide STA setup can be somewhat complex. Therefore, you are advised to keep the default factory settings and STA will automatically assign root bridges/ports and block loop connections. However, if you need to customize the STA parameters, refer to Table 5-1.
  • Page 36 Max. Age ≤ 2 x Forward Delay 4 - 30 sec. High # delays the change in state (Forward Delay - 1) Max. Age ≥ 2 x (Hello Time + 1) Port Level STA parameters Enable / Disable Enable / Enable or disable...

  • Page 37: Using The Console Interface

    NTERFACE Your Gigabit Ethernet Switch supports a console management interface that allows you to set up and control your Switch, either with an ordinary terminal (or terminal emulator), or over the network using the TCP/IP TELNET protocol. You can use this facility to perform many basic network management functions.

  • Page 38: Console Usage Conventions

    ♦ One stop bit You can also access the same functions over a TELNET interface. Once you have set an IP address for your Switch, you can use a TELNET program (in a VT-100 compatible terminal mode) to access and control the Switch. All of the screens are for the most part identical, whether accessed from the console port or from a TELNET interface.

  • Page 39: First Time Connecting To The Switch

    (shown below). Press Ctrl+R (hold down the Ctrl key, press the R key, and release both keys) to call up the screen, if the initial login screen does not appear. Also Ctrl+R can be used at any time to refresh the screen.

  • Page 40: Steps To Create Administrator Or Normal User Access

    1. Choose Add/Modify User Account from the User Account Management menu. The Add/Modify User Account menu appears. 2. Enter the new user name, assign an initial password, and then confirm the new password. Determine whether the new user should have Administrator or Normal User privileges. (Use the space bar to toggle between the two options).

  • Page 41: Administrator And Normal User Privileges

    Gigabit Ethernet Switch User’s Guide 4. Press Esc. to return to the previous screen or Ctrl+T to go to the root screen. 5. To see a listing of all user accounts and access levels, press Esc. Then choose View/Delete User Account. The View/Delete User Account screen appears.

  • Page 42: Save Configuration

    Table 6-1. Administrator and Normal User Privileges After establishing a User Account with Administrator-level privileges, press Esc. twice. Then choose the Save Changes menu (seen below). Pressing any key will return to the main menu. You are now ready to operate the Switch. Save Configuration In order to retain any modifications made in the current session, it is necessary to choose Save Configuration from the main menu.

  • Page 43: Add/Modify User Account

    Gigabit Ethernet Switch User’s Guide 1. Type in your Username and press Enter. 2. Type in your Password and press Enter. 3. The main menu screen will be displayed based on your Administrator or Normal User access level or privilege. Add/Modify User Account To add or change your user password: 1.
  • Page 44 Figure 6-5. Add/Modify User Account screen 3. Type in your Username and press Enter. 4. If you are a new user, type in the Old Password and press Enter. 5. Type in the New Password you have chosen, and press Enter.

  • Page 45: View/Delete User Account

    Management menu. The following screen appears: Figure 6-6. View/Delete User Account screen To delete your user password: 1. Toggle the Delete field of the user you wish to remove to Yes. 2. Press APPLY to let the user deletion take effect. Using the Console Interface...

  • Page 46: Setting Up The Switch

    TEG-S40SX main menu. The following menu appears: Figure 6-7. System Configuration menu You will need to change some settings to allow you to be able to manage the Switch from an SNMP-based Network Management System such as SNMP v1 or to be able to access the Switch using the TELNET protocol.
  • Page 47 Gigabit Ethernet Switch User’s Guide Configure IP Address The Switch needs to have a TCP/IP address assigned to it so that the network management system or TELNET client can find it on the network. The IP Configuration screen allows you to change...

  • Page 48: Configure Console

    IP address that determines where frames with a destination outside the current subnet should be sent. This is usually the address of a router or a host acting as an IP gateway. If your network is not part of an internetwork, or you do not want the Switch to be accessible outside your local network, you can leave this field blank.
  • Page 49 In this field, you can toggle between SLIP or Console port type settings. ♦ Baud Rate Determines the serial port bit rate that will be used the next time the Switch is restarted. Applies only when the serial port is being used for out-of-band (SLIP) management;...
  • Page 50 Gigabit Ethernet Switch User’s Guide Configure Switch The Switch Configuration screen shows various pieces of information about your Switch, and allows you to set the System Name, System Location, and System Contact. These settings can be retrieved from the Switch using SNMP requests, allowing these settings to be used for network management purposes.
  • Page 51 Switch. The Configure Advanced Switch Features screen allows you to enable or disable auto-partitioning on all ports as well as to enable or disable head of line blocking prevention. Press ADVANCE SETTINGS on the System Configuration window to access the Configure Advanced Switch Features screen: Figure 6-11.

  • Page 52: Configure Ports

    Great caution, however, must be observed when partitioning a port; you should make sure that the partitioned port is not being used as the port to control or monitor the condition of other devices.
  • Page 53 Gigabit Ethernet Switch User’s Guide 3. In the State field, change the port state to Enabled or Disabled. 4. In the Flow Ctrl field, toggle Off or On. 5. In the Priority field, select Normal, High or Low. 6. In the Broadcast Storm Rising Action and Broadcast Storm Falling Action fields, set the desired setting.
  • Page 54 You can attach a monitoring device to the mirrored port, such as a sniffer or an RMON probe, to view details about the packets passing through the first port. This is useful for network monitoring and troubleshooting purposes.
  • Page 55 Gigabit Ethernet Switch User’s Guide Figure 6-13. Port Mirroring Configuration screen To configure a mirror port, select the port from where you want to copy frames in the Source Port field. Then select the port which receives the copies from the source port in the Target Port field.
  • Page 56 System Configuration menu. The following Spanning Tree Protocol Configuration menu will be displayed: Figure 6-14. Spanning Tree Protocol Configuration menu 2. Choose STP Parameters Setting to access the following screen: Figure 6-15. STP Parameters Setting screen Using the Console Interface...
  • Page 57 Gigabit Ethernet Switch User’s Guide 3. Change the Disabled setting to Enabled in the Spanning Tree Protocol field. 4. Enter the Bridge Max Age in the Max Age(6-40 sec) field. 5. Enter the Bridge Hello Time in the Hello Time(1-10 sec) field.
  • Page 58 ♦ Max Age(6-40 Sec) Maximum Age is a read-write object that can be set from 6 to 40 seconds. At the end of the Maximum Age, if a BPDU has still not been received from the Root ridge, your Switch will start sending its own BPDU to all other switches for permission to become the Root Bridge.
  • Page 59 Gigabit Ethernet Switch User’s Guide ♦ Hello Time(1-10 Sec) Hello Time is a read-write object that can be set from 1 to 10 seconds. This is the interval between two transmissions of BPDU packets sent by the Root Bridge to tell all other switches that it is indeed the Root Bridge.
  • Page 60 Figure 6-16. STP Custom Setting screen 3. Change the Disabled setting of the STP State field to Enabled. 4. Set the path cost for the port between 1 and 65535 in the Cost field. 5. Set the priority for the port between 0 and 255 in the Priority field.
  • Page 61 Choose Configure Forwarding and Filtering Table from the Switch Configuration menu to access the following screen: Figure 6-17. Filtering and Forwarding Table Configuration screen The following fields at the top of the screen can be set: ♦ Lock Address Table(STOPs Learning) Mostly used for security purposes, when the forwarding table is locked the Switch will no longer learn the MAC addresses for new hosts.
  • Page 62 The status of the MAC address should show “in use”. By mapping a port to a destination MAC address, the switch can permanently forward traffic to the specified device, even after long periods of network inactivity or during times of network congestion.
  • Page 63 Custom Filtering Table. They are defined here briefly as follows. Dynamic Filtering is defined when a dynamic entry is created by the Learning Process as a result of observation of network traffic in the Filtering Database. Static Filtering is defined as static entries that may be added and removed from the Filtering Database by the user.

  • Page 64: Firmware And Configuration Update

    Gigabit Ethernet Switch User’s Guide Figure 6-19. Custom Filtering Table screen To make a change to the Custom Filtering Table, choose Add- Filter-Both or Remove in the Action field. Then enter the MAC Address and press APPLY. Firmware and Configuration Update...
  • Page 65 ♦ Firmware Update Determines whether or not the Switch will try to look for a runtime image file over the network. If set to Disabled, none of the fields below have any effect. ♦ File Name The pathname of the runtime image file on your TFTP server to be downloaded.

  • Page 66: System Utilities

    Gigabit Ethernet Switch User’s Guide ♦ Use Config File Toggle to Enabled to download config file during reboot. ♦ Config File Name The name of the configuration file to be downloaded. System Utilities The System Utilities menu features a Ping Test option. This sends a Ping to test network connectivity between the Switch and any other network device with an IP address.

  • Page 67: Snmp Configuration

    ♦ Repetition Amount of times the Switch should send the Ping (1-255). If zero is chosen, the Switch will continue Pinging indefinitely. In the lower part of the Ping Test screen, you can view the Ping status, including Result, Reply, Time out, and Unreachable. SNMP Configuration...
  • Page 68 A community name is an arbitrary string of characters used as a “password” to control access to the Switch. If the Switch receives a request with a community name it does not recognize, it will trigger an authentication trap.

  • Page 69: Switch Monitoring

    ♦ IP Address The IP address of the network management station to receive the trap. Switch Monitoring The Switch allows you to keep statistics on the operation of each port. The statistics obtained can be used to monitor the conditions and general efficiency of the Switch.
  • Page 70 The information displayed above includes: ♦ Update Interval Select the desired update increment setting from: 1 sec, 5 sec, 15 sec, 30 sec, 1 min, or Suspend. ♦ TX/sec The number of good bytes sent from the respective port per second.
  • Page 71 ♦ Update Interval Select the desired update increment setting from: 1 sec, 5 sec, 15 sec, 30 sec, 1 min, or Suspend. ♦ Speed The speed for each port is 1000M. When a link is up “1000M/Full” will be displayed. When a link is down “–“ will be displayed.
  • Page 72 Gigabit Ethernet Switch User’s Guide ♦ Bytes Sent The number of good bytes sent from the respective port. ♦ Frames Recv. The number of good frames received. This also includes local and dropped packets. ♦ Frames Sent The number of good frames sent from the respective port.
  • Page 73 Gigabit Ethernet Switch User’s Guide Figure 6-26. Port Error Packet Statistics table The information displayed above includes: ♦ Ports This field always displays “1 to 4” in this 4-port Switch version. ♦ Update Interval Select the desired update increment setting from: 1 sec, 5 sec, 15 sec, 30 sec, 1 min, or Suspend.
  • Page 74 Gigabit Ethernet Switch User’s Guide ♦ Late Collisions The number of collisions that occur at or after the 64 byte (octet) in the frame. ♦ Mac Rx Errors The number of frames with received MAC Errors. ♦ Dropped Frames Counts received...
  • Page 75 ♦ Port Enter the desired port in this field. ♦ Update Interval Select the desired update increment setting from: 1 sec, 5 sec, 15 sec, 30 sec, 1 min, or Suspend. ♦ 64, 65-127, 128-255, 256-511, 512-1023, 1024-1518 number of good frames of various length ranges, both valid and invalid.

  • Page 76: Forwarding Table

    The Forwarding Table allows the user to view which Switch port(s) a specific network device uses to communicate on the network. You can sort this table by MAC address or port. This is useful for viewing which ports one device is using, or which devices are using one port.

  • Page 77: Resetting The Switch

    You can use the console interface to reset the Switch, either doing a Restart System (which restarts the Switch and is identical to powering the Switch off and back on again) or a Factory Reset to Default Value (which sets all of the Switch’s parameters to what they were when the Switch was delivered from the factory).

  • Page 78: Restart System

    Factory Reset to Default Value Before performing a factory reset, be absolutely certain that this is what you want to do. Once the reset is done, all of the Switch’s settings stored in NV-RAM (including TCP/IP parameters, SNMP parameters, the enabled/disabled settings of ports, security settings, etc.) will be erased and restored to their factory default...

  • Page 79: Logout

    Gigabit Ethernet Switch User’s Guide Figure 6-30. Factory Reset to Default Value screen 2. Move the cursor to Yes to confirm the reset and press Enter. The main menu screen should appear. Logout To exit the Switch, choose Logout from the main menu. You will be returned to the opening login screen.

  • Page 81: Web-Based Network Management

    Netscape Navigator/Communicator or Microsoft Internet Explorer. The Web browser acts as a universal access tool and can communicate directly with the Switch using HTTP protocol. Your browser screen may vary with the screen shots (pictures) in this guide.

  • Page 82: Getting Started

    Internet Explorer. Follow the installation instructions for the browser. The second and last step is to configure the IP interface of the Switch. This can be done manually through a console (see the Configure IP Address section in the “Using The Console Interface”...

  • Page 83: Configuration

    Gigabit Ethernet Switch User’s Guide connects you to a help program) causes a list of options to appear underneath the major category. All categories and options are explained below. Configuration This is the first category and is opened by default when you...
  • Page 84 ♦ System Uptime Amount of time the Switch has been powered on. ♦ Runtime Software Version This version number of the software. ♦ PROM Firmware Version Version number of the firmware stored in the Flash memory of the Switch.
  • Page 85 Gigabit Ethernet Switch User’s Guide You can change the IP Address, Subnet Mask, and Default Gateway on the Switch. If you are not using BOOTP, enter the IP Address, Subnet Mask, and Default Gateway of the Switch. If you enable BOOTP, you do not need to configure any IP parameters because a BOOTP server automatically assigns IP configuration parameters to the Switch.
  • Page 86 The Switch features head of line (HOL) blocking prevention, a function designed to prevent forwarding a packet to a “blocking” port, that is, a port where an excess of packets are queued up. Note that when a multicast packet or a packet with an unknown destination address needs to be forwarded to several ports, and if some of them are “blocking,”...
  • Page 87 Ports Setup Select the port you want to configure by clicking on the port in the Switch front panel display at the top of the screen or by using the screen displayed above. Follow these steps: 1. Enable or disable the port. If you choose Disabled, devices...

  • Page 88: Port Mirror

    Port Mirror The Switch allows you to copy frames transmitted and received on a port and redirect the copies to another port. You can attach a monitoring device to the mirrored port, such as a sniffer or an RMON probe, to view details about the packets passing through the first port.

  • Page 89: Trap Manager

    To use the trap manager function featured on this Switch, enter the desired community string and IP address of the trap receiving station (up to four are allowed). A trap receiving station is a device that constantly runs a network management application to receive and store traps.
  • Page 90 SNMP management on the Switch in the Community String field and the desired Access Right setting in the next field. You may enter up to four IP addresses of trap receiving stations in the Trap Manager window of the Configuration section. Then click Apply to put the settings into effect.
  • Page 91 ♦ Firmware Update Determines whether or not the Switch should download its new firmware code the next time it is booted. ♦ File Name The path and the name of the file which holds the new firmware code on the TFTP server. Web-Based Network Management...
  • Page 92 ♦ Config File Name The path and configuration name on the TFTP server. ♦ Last TFTP Server Address The IP address of the TFTP server where the configuration file was located in the last configuration change. Console...
  • Page 93 The options for the current console port setting are Console or Slip. ♦ Baud Rate Determines the serial port bit rate that will be used the next time the Switch is restarted. Applies only when the serial port is being used for out-of-band (SLIP) management;...
  • Page 94 Gigabit Ethernet Switch User’s Guide Save To save all changes made in the current session to the Switch’s flash memory, click the Apply button on this screen. Web-Based Network Management...

  • Page 95: Bridge

    Gigabit Ethernet Switch User’s Guide Reset Doing a remote reset is equivalent to turning the Switch off and on again. All parameters are returned to the values stored in EEPROM. Bridge This is the second category of the Web-based management program.
  • Page 96 The Switch supports 801.2d Spanning Tree Protocol, which allows you to create alternative paths (with multiple switches or other types of bridges) in your network. See the Spanning Tree Algorithm section of the “Switch Management” chapter for a detailed explanation.
  • Page 97 STP root. ♦ Root Cost Read-only object displays the cost for the path between the switch and the root bridge. If the switch is the root bridge, then the root cost is zero. ♦ Root Port Read-only object identifies the port (on the bridge) that offers the least path cost from the bridge to the root bridge.
  • Page 98 Bridge. ♦ Bridge Hello Time (1-10 Sec) The Hello Time is a read- write object that can be from 1 to 10 seconds. This is the interval between two transmissions of BPDU packets sent by the Root Bridge to tell all other switches that it is indeed the Root Bridge.

  • Page 99: Port Stp

    ♦ Priority The read-write object displays the priority number of the port. The value is used in conjunction with the physical port number to set the port ID, which in turn is used when determining the root port of the bridge. The...
  • Page 100 The higher the port priority, the more chances the port has of becoming the root port. Port priority ranges from 0 to 255, with 0 being the highest port priority.
  • Page 101 Gigabit Ethernet Switch User’s Guide Custom FDB To use the MAC forwarding function, enter the MAC address of the device to which the specified port permanently forwards traffic in the Destination Address field and enter the port number that permanently forwards traffic from the specified device in the Destination Port field.
  • Page 102 Gigabit Ethernet Switch User’s Guide Filter Table MAC filtering allows the Switch to block inbound traffic from unknown or unwanted devices by mapping a port to a source MAC address. To use the MAC filtering function, enter the MAC address of the device allowed to send traffic in the MAC Address field and select the desired setting in the Filter Status field.

  • Page 103: Monitor

    This is the third category of the Web-based management program. The Monitor options are listed below along with explanations for each one. Overview The information on the Switch Statistics table is described as follows: ♦ TX frames/sec Counts the total number of frames transmitted from a selected port per second since the Switch was last rebooted.
  • Page 104 Gigabit Ethernet Switch User’s Guide Traffic The port statistics shown by default are those for the port you last configured. Once in the Port Statistics screens, you can click any port on the switch graphic to show statistics for that port.
  • Page 105 Gigabit Ethernet Switch User’s Guide ♦ Bytes Sent Counts the number of bytes successfully sent from the port. ♦ Bytes Received Counts the total number of bytes (octets) included in valid (readable) frames. ♦ Total Bytes Received Counts the total number of bytes received on the port, whether in valid or invalid frames.
  • Page 106 (Link Down).. ♦ Jabber Counts frames longer than the maximum 1518 bytes (octets) with either bad framing or an invalid CRC. ♦ Dropped Frames Counts received packets which are dropped due to any of the following reasons: lack of...
  • Page 107 ♦ Late Collision Counts collisions that occur at or after the 64 byte (octet) in the frame. This may indicate that delays on your Ethernet are too long, and you have either exceeded the repeater count or cable length specified in the Ethernet standard.
  • Page 108 ♦ Update Interval The polling time interval can be set from 5 to 60 seconds, in 5 second increments. Click the Submit button once the update interval has been selected. ♦ 64 The total number of packets (including bad packets) received that were 64 octets in length (excluding framing bits but including FCS octets).
  • Page 109 1024 and 1518 octets in length inclusive (excluding framing bits but including FCS octets). ♦ RX (good) The number of good frames received. This also includes local and dropped packets. ♦ TX (good) The number of good frames sent from the respective port.

  • Page 110: User

    Password, and Confirm New Password fields. Then select General User or Administrator in the Access Level control and click Apply. To delete a User Account, click the “X” icon in the delete column on the User Account Table at the bottom of the screen.

  • Page 111: Help

    Gigabit Ethernet Switch User’s Guide Help Click this button to access the online help files for the Switch. Web-Based Network Management...

  • Page 112: Technical Specifications

    Gigabit Ethernet Switch User’s Guide ECHNICAL PECIFICATIONS General Standards: IEEE 802.3z on each port IEEE 802.3 Frame types: Transparent IEEE 802.3 MAC layer frame size: 64–1518 bytes Protocol: CSMA/CD Data Transfer Rate: Gigabit Ethernet: 2000Mbps (full duplex) Topology: Star Network 525 m 50/125-mm, 275 m 62.5/125-mm multimode fiber...

  • Page 113: Physical And Environmental

    -20 ~ 60 degree Celsius Temperature: Humidity: 0% ~ 90% RH non-condensing Dimensions: 441 mm x 207 mm x 44 mm (1U), 19 inch rack-mount width Weight: 3 kg EMI: FCC Class A, CE Mark Class A, VCCI Class A, BSMI...

  • Page 114: Index

    Gigabit Ethernet Switch User’s Guide Performance Rate: MAC Address Learning: Self-learning, auto-aging INDEX AC power cord, 6 % of Utilization, 95 Access Level, 102 % Utilization, 63 Access Right, 61, 82 %Util., 62 Access Rights read/write, 61 :Root Port, 24...
  • Page 115 Gigabit Ethernet Switch User’s Guide Authentication Failure, 20 Bridge MIB (RFC 1493), 5 Automatic learning, 22 Bridge Priority, 24 Automatic topology re- Bridge Priority, 25, 27 configuration Bridge Priority (0-65535 Spanning Tree Algorithm, Sec), 90 Bridge Priority(0-65535 Sec), 51 Basic Setup, 75...
  • Page 116 Gigabit Ethernet Switch User’s Guide CRC Errors, 63, 65, 67 Config File Name, 58, 84 Configuration, 75 Custom FDB, 93 Configure Advanced Switch Custom Filtering Table, 55, Features, 43 Configure Console, 40 Custom Forwarding Table, 53 Configure Filtering and Data Bits, 85...
  • Page 117 Gigabit Ethernet Switch User’s Guide Factory Reset to Default Full duplex, 4 Value, 70 Full LED indicator, 14 FDB Table, 92 General User , 102 Features, 3 File Name, 57, 83 Hardware Revision, 76 Filter Status, 94 head of line (HOL) blocking...
  • Page 118 LED Indicators, 13 Link Change Event, 20 Multicast TX, 68 Link Status, 96, 98 Network Classes Link/Act LED indicator, 14 Class A, B, C for Subnet Local console management, 17 Mask, 40 Lock Address Table(STOPs Network loop detection and Learning), 53...
  • Page 119 Gigabit Ethernet Switch User’s Guide Power LED indicator, 13 Packet Forwarding, 21 Power on, 9 Parity, 85 Prevent Unauthorized Users, Path Cost, 91 Path Cost, 25 Priority, 45, 52, 80, 91 PC to Switch, 15 PROM Firmware Version, 76 Performance features, 4...
  • Page 120 Gigabit Ethernet Switch User’s Guide Root Port, 50, 89 Software Update Mode, 57, Root Priority, 50 Root Priority(Sec), 89 Source Port, 47 Routers, 3 Spanning Tree Algorithm RS-232 DCE console port, 17 (STA), 22 Runtime Software Version, Spanning Tree Algorithm...
  • Page 121 16 Switching Technology, 2 software, 21 System Configuration, 38, Time Since Topology Changes(sec), 49, 88 39, 40, 42, 44, 46, 48, 51, 54, 55 Topology Change, 20 System Contact, 42, 43, 75 Topology Change Count, 49, System Description, 76...
  • Page 122 Gigabit Ethernet Switch User’s Guide User-Changeblel Parameters, TX Bytes, 101 TX frames/sec, 95 TX Octets, 67 Username, 36 Using the Console Interface, TX/sec, 62 Unicast, 101 utilization, 45 Unicast RX, 68 Utilization, 96, 97 Unicast TX, 68 ventilation, 7 Unpacking, 6 Unpacking and Setup, 6–10...
