- Page 1 Quick Installation Guide TEG-S2400i TEG-S2600i...
-
Page 2: Table Of Contents
Table of Contents English ...................... 1. Before You Start ................. 2. How to Connect ................. 3. Using the Switch ................Troubleshooting ..................Version 10.31.05... -
Page 3: English
1. Before You Start Package Content TEG- 2400i/TEG- 2600i Quick Installation Guide User’s Guide CD-ROM AC power cord RS-232 cable Rack Mount Kit Application TEG-S2400i/TEG-S2600i Multi-mode Mini GBIC Module (TEG-MGBSX) Workstations with Fast Ethernet Card (TE100-PCIWN) Server with 1000Mbps Copper Gigabit PCI Adapter... -
Page 4: How To Connect
2. How to Connect 1. Connect the AC Power cord to the back of the TEG-S2400i/TEG-S2600i. 2. Connect the network cable to the front of the switch and your PC. 3. Verify that the PWR led displays a solid green light. -
Page 5: Using The Switch
3. Using the Switch 1. Go to Start > Settings > Control Panel. 2. Double-Click the Network Connection Icon. 3. Right-Click Local Area Connection, and select Properties. English... - Page 6 5. Open your web browser, type http://192.168.223.100, and press Enter. 6. User Name: admin Password: 123 7. Select the appropriate option to configure the SNMP switch. Your installation is now complete. Note: For more detail on advanced features, please consult the User's Guide. English...
-
Page 7: Troubleshooting
How come I cannot see any light from any of my LED's? Your TEG-S2400i/TEG-S2600i is not getting any power. Make sure that your surge protector or your outlet is getting power and make sure that the AC Power cord is properly connected to your switch. - Page 8 Limited Warranty TRENDnet warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase. TEG-S2400i/TEG-S2600i - 5-Year Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or deliver to customer an equivalent product to replace the defective item.
- Page 9 LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE. Governing Law: This Limited Warranty shall be governed by the laws of the state of California. Note: AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1-Year Warranty...
- Page 10 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 11 Telephone: +(31) (0) 20 504 05 35 English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com 20675 Manhattan Place Torrance, CA 90501...
