INFO
T-OUT (Tim
Delay
Actual))
SYNC-IN
(Pol
Filter)
TRIG-IN
Trigger timing setting when SYNC-OUT output is set to TRIG-OUT.
Trigger signal is output at the center timing of the next
Center
frame.
Through Outputs the trigger input signal as it is.
Trigger signal is output at the timing of the delay time
Delay
setting from the start of the next frame.
Numeric en- Sets the delay time between the start of the next frame
try and the output of the trigger signal. (Setting in µs)
Actual delay time ( µs )
Selection of connector applications.
Signal input is not used.
* When both SYNC-IN and EST2 are set to None, the set-
None
tings are switched to the internal time and internal syn-
chronization settings.
When EST
signal is input
Auto
When no sig-
nal is input
When EST
signal is input
EST
When no sig-
nal is input
W h e n I R I G
signal is input
Time
When no sig-
nal is input
Signal setting when SYNC-IN is set to EST
H-L Exposure starts at H to L transition.
L-H Exposure starts at L to H transition.
Numeric en- Filter setting for high external noise. ( Setting in µs )
try Applicable to EST signals only.
Selection of external trigger signal.
None Signal input not used.
Trigger Used as trigger signal input
EST synchronization
Can operate without synchronization
EST synchronization
Operation stopped (waiting for signal)
IRIG synchronization
Can operate without synchronization
60
