Connector
USB2.0 connector
Application
Model
Compatible Plug
Number of Connectors
Standard
Pin Configuration
Pin No. Name
1 VBUS
2 D-
3 D+
4 GND
Shell FRAME GND
Pin Configuration Figure (from the side of the engaged connector)
USB3.1 connector
Application
Model
Compatible Plug
Number of Connectors
Standard
USB device connection (for firmware and internal updates)
Standard-A Receptacle
Standard-A Plug
1
Compatible with USB2.0 standards and USB HOST, exFAT/NTFS
Direction Function • Input/Output Level
OUT USB power output, 5V/1.0A
I/O
I/O
OUT USB power output return
-
USB device connection
USB Type-C Receptacle(JAE DX07S024JAAR1100)
USB Type-C Plug
1
Compatible with USB3.1 standards and USB HOST, exFAT/NTFS
150
USB2.0 HS signal
USB2.0 HS signal
Notes
