PLAY
Guide
A2
A1 A3
Guide
Check box
1 By selecting the "Guide" check box, a guide will appear perpendicular to the line segment
at the two drawn points.
When drawing a line segment with three or more points, a guide is displayed on the line
segment connecting the selected point and the previous point. In the example, A3 is se-
lected, so the guide is displayed on the A2-A3 line segment.
Line segments can be drawn on the diameter of a circle and used as tangents to the cir-
cle to support measurement.
