NAC Image Technology MEMRECAM GO-4K User Manual page 31

AC adapter and battery used together.
(1) Install the battery plate. Connect the power cable of the plate to the camera.
(2) Install the battery. Connect the DC cable of the AC adapter to the power input of the bat-
tery.
(3) Attach the battery to the battery plate.
(4) Turn on the power switch of the AC adapter.
(5) Press the power button on the camera.
(1)
(3)
Connect the cable plug with the red circle
facing up. Insert the plug all the way to
the back until it locks into place.
(00519)
(2)
The LED on the battery plate lights up.
(4)
P l u g r e d
circle
The LED on the AC adapt-
er lights up.
31
Until the power is turned on
(5)
Make sure that POW-
ER LED changes from
lit in orange to flash
in blue.
The power LED lights
in white when start-
up is complete.
