External Appearance and Names of Each Part
Rear panel
4
6
7
17
18
1 CAMERA MODE LED
2 PWR BTN & POWER LED
3 E-paper
4 EPAPER BTN & LED
5 FUNC BTN 3
6 DC-IN connector
7 REMOTE connector
8 ETHERNET LED
9 SYNC-OUT connector
10 SYNC-IN connector
2 3
9 10
1 8
11
11 TRIG connector
12 FUNC BTN 1
13 FUNC BTN 2
14 USB 2.0 connector
15 USB 3.1 connector
16 EJECT BTN & LED
Product name plate(shows the product
17
number)
18 RESET BTN
10
5
12
13
14
15
16
