Connector
SYNC-IN connector
Application
Model
Compatible Plug
Signal Level
EST function
IRIG function
Pin Configuration
Pin No. Name
1 SYNC-IN
Shell SYNC-IN RTN
EST/IRIG-DCLS input (select one)
BNC receptacle R132-002612000
BNC plug
TTL level, 5V pull-up resistor 4700 Ω, isolation
L level:-0.5V (min. applied voltage) to 0.5V
H Level: 2V to 5.5V (max. applied voltage)
Set the camera to EST mode and start exposure at H to L of this in-
put to record a single image. Contact input possible. With polarity
inversion function
Synchronous precision of 40nS or less
When inputting EVENT, the signal-level is recorded together with the
image.
The time is synchronized as a IRIG-B DCLS.
Direction Function • Input/Output Level
IN
IN
144
TTL, contact point
TTL, contact point
Notes
Isolation
Ground insulator
