PLAY
Luminance graph
Button
Display frame num-
ber
Play
Playback range set-
ting
Playback range
Luminance graph
scaling
Loop
Playback speed
A graph of the total luminance values of the displayed frames. It
makes it easier to look for phenomena with changes in luminance.
Function
Displays the frame number of the displayed image.
Tap to enter a numerical value and directly specify the
frame.
Playback. The direction of playback changes with the
direction of the button.
Set the playback range. Tap to specify the start and
end of playback, respectively.
Displays the playback range. Tap to enter a numerical
value to specify the range.
The display range of the luminance graph can be
zoomed in and out.
Repeats playback of the specified range.
Playback speed can be changed.
Set the speed using the pull-down menu.
