Connecting Ethernet cable

GO-4K uses a simple J3 cable/J3 branch cable (optional) to connect Ethernet cables.
J3 Cable Type
The J3 cable is an optional cable common to MEMRECAM series.
J3 branch cable
Cable No
Simple J3 cable
• GO-4K does not support EPO output from the REMOTE connector.
• Some MEMRECAM series models do not have a connector for the J3 cable.
(00519)
Ethernet cable connection connector and various input/output connectors
Ethernet cable connector.
25
Adjust the Lens Aperture
Connectors
ETHER
EST2
IRIG-B
TRIG2
EPO
(GO-4K not supported)
PWRCNT
Connector
ETHER
