External Appearance and Names of Each Part
ETHERNET LED
LED Status
Yellow-green Linking in 1000BASE-T.
Orange Linking in 100BASE-TX.
Not lit Not connected to network or powered off.
EJECT LED & BTN (LED and button are integrated)
LED Status
Flashing Blue The camera is recognizing the connected device.
External USB storage connected to USB2.0 connector. Ready for storage.
Yellow-green USB3.1 connector with external USB storage device not compatible with
USB3. Ready for storage.
USB3 capable external USB storage-attached to USB3.1 connector. Stor-
White
able status.
Flashing Data storage to the external USB storage started, but USB storage is not
green connected and the storage is waiting to be saved. Blinks in synchronization
(Low speed) with CAMERA MODE LED.
Flashing
Data-saving to external USB storage. (Common to USB3.1 and USB2.0
green
Connectors)
(High speed)
Removable external USB storage. No external USB storage-connected.
Not lit Unavailable external USB storage connectivity status (Format USB stor-
age).
Operation
Press the
Removing external USB storage.
button
Operation
Operation
Function
