Technical Specifications - Altronix NetWay4E1 Series Installation Manual

Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily
usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 For use with Single-Mode Fiber for distances up to 10km.
P1AB2K For use with Single Strand Single-Mode Fiber for distances up to 2km.
P1GCE For use with CAT5e or better for distances up to 100m.
Recommended Altronix Power Sourcing Equipment:
NetWaySP4P
Ethernet to Fiber Media Converter with Integral Power Supply/Charger.
Four (4) 56VDC non power-limited outputs up to 120W max. full power per port
(240W total power). Four (4) 1Gb SFP ports.
NetWaySP4PX Ethernet to Fiber Media Converter with Integral Power Supply/Charger.
Four (4) 56VDC non power-limited outputs up to 120W max. full power per port
(480W total power). Four (4) 1Gb SFP ports.
NetWaySP4P2 Ethernet to Fiber Media Converter with Integral Power-Limited Power Supply/Charger.
Four (4) 56VDC power-limited outputs up to 60W max. full power per port
(240W total power). Four (4) 1Gb SFP ports.
WayPoint562
High Current Outdoor Power Supply/Charger. 56VDC/120W output.
Filtered and electronically regulated output. Short circuit and thermal overload protection.
Vertiline563 EIA 19" 1U Rack Mountable Dual Independent Power Supply/Charger.
56VDC @ 3A each output.
Filtered and electronically regulated output. Short circuit and thermal overload protection.
PoE201
Power Supply/Charger Board. 56VDC/120W output.
Filtered and electronically regulated output. Short circuit and thermal overload protection.
Parameter Description
Number of
Four (4) 10/100/1000 Mbps Ethernet ports rated at 30W each.
Ports
IEEE 802.3af, 802.3at compliant. One (1) Gigabit SFP Port.
NetWay4E1WP/NetWay4E1PL/NetWay4E1WPX/NetWay4E1X:
Input Power
115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
Requirements
NetWay4E1B/NetWay4E1WPN: 48-56V UL Listed ITE power supply.
Operating Ambient Temperature:
Environmental
Conditions
Storage Temperature: – 30ºC to 85ºC (– 22ºF to 185ºF).
Relative Humidity:
Operating Altitude:
Weights
(approx.)
- 4 -
Recommended Altronix SFP Modules:

Technical Specifications:

60W: – 40ºC to 75ºC (– 40ºF to 167ºF);
75W: – 40ºC to 70ºC (– 40ºF to 158ºF);
100W: – 40ºC to 55ºC (– 40ºF to 131ºF);
120W: – 40ºC to 45ºC (– 40ºF to 113ºF).
85%, +/– 5%
– 304.8 to 2,000m.
Model
NetWay4E1WP
NetWay4E1WPN
NetWay4E1WPX
NetWay4E1X
NetWay4E1PL
NetWay4E1B
Product Weight
10.5 lb. (4.76 kg)
9.5 lb. (4.3 kg)
15 lb. (6.8 kg)
6.65 lb. (3.02 kg)
2.6 lb. (1.18 kg)
0.4 lb. (0.18 kg)
Shipping Weight
11.9 lb. (5.4 kg)
10.9 lb. (4.9 kg)
17.5 lb. (7.9kg)
7.55 lb. (3.42kg)
4.0 lb. (1.81kg)
0.75 lb. (0.34 kg)
Netway4E1 Series Installation Guide
