3. Connect structured cables from port marked [Port 1] to [Port 8] on NetWay unit to PoE-compliant cameras/
edge devices (Fig. 4, pg. 10). Note: All interconnected devices must be UL Listed.
4. Insert SFP module into port(s) marked [SFP], then connect cable to the SFP module on NetWaySP8B to the
corresponding input of an SFP switch (Fig. 4, pg. 10).
6. Battery Backup (if desired): Connect either two (2) sealed lead acid or gel-type 12VDC batteries wired in
series or one (1) LiFePO 4 (lithium iron phosphate) battery to terminals marked [– BAT +] (Fig. 4, pg. 10),
carefully observing polarity.
Note: When batteries are not used, a loss of AC will result in the loss of output voltage.
7. Please ensure that the cover is secured with:
Key lock and screws for NetWaySP8X2, security bolt for NetWaySP8WP2/NetWaySP8WPX2.
P1MM - For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 - For use with Single-Mode Fiber for distances up to 10km.
P1AB2K - For use with Single-Mode Single Strand Fiber for distances 2km.
P1GCE - For use with CAT5e or better copper ethernet for distances up to 100m.
Parameter Description
Number of Ports Eight (8) ports PoE+ (30W) or up to two (2) Hi-PoE (60W) ports. Two (2) Gigabit SFP Ports.
Input Power
115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
Requirements
Operating Ambient Temperature:
Environmental
Conditions
Storage Temperature: – 30ºC to 85ºC (– 22ºF to 185ºF).
Relative Humidity: 85%, +/– 5%
Operating Altitude: – 304.8 to 2,000m.
Weights (approx.)
NetWaySP82 Series Installation Guide

Recommended Altronix SFP Modules:

Technical Specifications:

180W: – 30ºC to 65ºC (– 22ºF to 149ºF);
150W: – 30ºC to 75ºC (– 22ºF to 167ºF);
Model
NetWaySP8WP2
NetWaySP8WPX2
NetWaySP8X2
NetWaySP8PL2
Product Weight
10.72 lbs. (4.86 kg)
15 lbs. (6.8 kg)
6.85 lbs. (3.11 kg)
2.8 lbs. (1.27 kg)
Shipping Weight
12.1 lbs. (5.49 kg)
17.5 lbs. (7.9kg)
7.75 lbs. (3.51 kg)
4.2 lbs. (1.9 kg)
