Terminal/Port
Function/Description
Legend
Connect a 24VDC UL Listed power source to these terminals carefully observing polarity.
GND +24V Factory connected to power supply in NetWay5PWP, NetWay5PWPX, NetWay5PX
(Fig. 1a, pg. 4)
Data Input Can be used as a Data Uplink (Fig. 1b, pg. 4).
Data and PoE/PoE+ (IEEE 802.3af (15W) and IEEE 802.3at (30W) compliant) ports
Port 1 - Port 4
(Fig. 1c, pg. 4).
eFlow104NB Power Supply/Charger
Terminal Legend Function/Description
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral (non power-limited)
L, N
(Fig. 2a, pg. 4).
– DC + 24VDC nominal @ 10A continuous output factory connected to NetWay5P (Fig. 2h, pg. 4).
Trigger EOL Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally open,
Supervised normally closed from an FACP output circuit (power-limited input) (Fig. 2d, pg. 4).
NO, GND RESET FACP interface latching or non-latching (power-limited) (Fig. 2e, pg. 4).
+ AUX – Auxiliary Class 2 power-limited output rated @ 1A (unswitched) (Fig. 2f, pg. 4).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
AC Fail
Relay normally energized when AC power is present.
NC, C, NO
Contact rating 1A @ 30VDC (power-limited) (Fig. 2b, pg. 4).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized when
Bat Fail DC power is present. Contact rating 1A @ 30VDC.
NC, C, NO A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (power-limited) (Fig. 2b, pg. 4).
Stand-by battery connections. Maximum charge current 1.54A (non power-limited)
– BAT +
(Fig. 2g, pg. 4).
Parameter Description
NetWay5PWP, NetWay5PWPX, NetWay5PX: 120VAC, 60Hz, 4.5A.
Input Power
NetWay5P/NetWay5PWPN: 24VDC from a UL Listed power source or a solar panel with
Requirements
nominal 24V (~18-35V) output.Current draw: 6A at maximum120W output.
Output Four (4) PoE/PoE+ ports. Single data uplink port.
NetWay5P:
Indicators
eFlow104NB: AC input and DC output LED indicators.
Operating Ambient Temperature:
Environmental Storage Temperature:
Conditions Humidity:
Operating Altitude:
Weights
(approx.)
NetWay5P Series Installation Guide
Terminal and Port Identification:

Technical Specifications:

Individual PoE On LEDs for each port.
Individual IP Link status, 100/1000Base-T/active LEDs for each port.
Model
NetWay5PWP
NetWay5PWPN
NetWay5PWPX
NetWay5PX
NetWay5P
30ºC to 70ºC (
– –
40ºC to 85ºC ( 40ºF to 185ºF).
– –
20 to 85%, non-condensing.
304.8 to 2,000m.
–
Product Weight
10.5 lb. (4.76 kg)
3.7 lb. (1.68 kg)
15 lb. (6.8 kg)
6.65 lb. (3.02 kg)
0.25 lb. (0.11 kg)
22ºF to 158ºF).
Shipping Weight
11.9 lb. (5.4 kg)
5 lb. (2.27 kg)
17.5 lb. (7.9kg)
7.55 lb. (3.42kg)
0.75 lb. (0.34 kg)
