Technical Specifications - Altronix NetWay5BT Series Installation Manual

Terminal/Port
Function/Description
Legend
Connect a 48-56V UL Listed power source to these terminals carefully observing polarity.
GND +54V Factory connected to power supply in NetWay5BTWP, NetWay5BTPL, NetWay5BTWPX,
NetWay5BTX (Fig. 1a, pg. 4)
Data Input Can be used as a Data Uplink (Fig. 1b, pg. 4).
Port 1 - Port 4 Data and PoE/PoE+ (IEEE802.3af/3at/3bt compliant) ports (Fig. 1c, pg. 4).
Parameter Description
NetWay5BTWP, NetWay5BTWPX, NetWay5BTX, NetWay5BTPL:
Input Power
Requirements
NetWay5BT/NetWay5BTWPN: 48-56V from a UL Listed power source.
Output
Four (4) PoE/PoE+ ports. Single data uplink port.
NetWay5BT:
Indicators
Operating Ambient Temperature:
Environmental
Conditions
Storage Temperature: – 30ºC to 85ºC (– 22ºF to 185ºF)
Relative Humidity:
Operating Altitude:
Weights
(approx.)
NetWay5PBT Series Installation Guide
Terminal and Port Identification:

Technical Specifications:

115VAC, 60Hz, 1.8A or 230VAC, 50/60Hz, 1A.
Individual PoE On LEDs for each port.
Individual IP Link status, 100/1000Base-T/active LEDs for each port.
240W:
– 30ºC to 55ºC (– 22ºF to 131ºF)
180W:
– 30ºC to 65ºC (– 22ºF to 149ºF)
150W: – 30ºC to 75ºC (– 22ºF to 167ºF).
85%, +/– 5%
– 304.8 to 2,000m
Model
NetWay5BTWP
NetWay5BTWPN
NetWay5BTWPX
NetWay5BTX
NetWay5BTPL
NetWay5BT
Product Weight
10.5 lb. (4.76 kg)
3.7 lb. (1.68 kg)
15 lb. (6.8 kg)
6.65 lb. (3.02 kg)
2.6 lb. (1.18 kg)
0.25 lb. (0.11 kg)
Shipping Weight
11.9 lb. (5.4 kg)
5 lb. (2.27 kg)
17.5 lb. (7.9kg)
7.55 lb. (3.42kg)
2.6 lb. (1.18 kg)
0.75 lb. (0.34 kg)
- 5 -
