Typical Application; Technical Specifications - Altronix NetWay SP2P Series Manual

Fig. 5
48-56VDC
Input
PoE+ (30W) PTZ
Parameter Description
One (1) 1Gb SFP port.
Ports
Two (2) PoE .3af/ .3at Ethernet ports 10/100/1000 Mbps.
NetWaySP2P/NetWaySP2PWPN:
Input Power
Requirements
NetWaySP2PWP/NetWaySP2PWPX:
PoE Green LED: Indicates PoE present.
Indicators
Fiber Signal Green LED: Indicates SFP connection.
Temperature:
Evironmental
Conditions
Relative Humidity:
Operating Altitude:
Regulatory
Compliance
NetWaySP2P:
Weights NetWaySP2PWPN:
(approx.) NetWaySP2PWP:
NetWaySP2PWPX:
- 8 -

Typical Application:

Brooklyn, NY, U.S.A.
NetWaySP2P
2-Port Media Converter/Injector
Input:
48–56VDC
Output: IEEE 802.3at (30W) and
IEEE 802.3af (15.4W)
compliant.
48-56VDC PoE+ PoE+
-- Input + Output Output
CAT5e/6

Technical Specifications:

Operating (30W):
Storage:
CE European Conformity.
NetWaySP2P
www.altronix.com
Converts Fiber
to Ethernet & Provides PoE
Fiber
SFP Signal
PoE+ (30W) PTZ
CAT5e/6
48VDC-56VDC @ 1.2A.
115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
– 40ºC to 70ºC (– 40ºF to 158ºF).
– 40ºC to 75ºC (– 40ºF to 167ºF).
85% +/–5%.
– 304.8 to 2,000m.
Product: 0.25 lb. (0.11 kg) | Shipping: 0.3 lb. (0.14 kg).
Product: 3.7 lb. (1.68 kg)
Product: 10.5 lb. (4.76 kg) | Shipping: 11.9 lb. (5.4 kg).
Product: 15 lb. (6.8 kg)
Fiber
| Shipping: 5 lb. (2.27 kg).
| Shipping: 17.5 lb. (7.9 kg).
NetWaySP2P Series Installation Guide
