Technical Specifications; Factory Default Settings; Network Settings - Altronix Netway Spectrum Series Installation Manual

Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily
usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM - For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 - For use with Single-Mode Fiber for distances up to 10km.
P1AB2K - For use with Single Strand Single-Mode Fiber for distances up to 2km.
P1GCE - For use with CAT5e or better for distances up to 100m.
Parameter
Number of Ports
Input Power
Requirements
Environmental
Conditions
Weights (approx.)
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––

Factory Default Settings

• IP Address:
• User Name:
• Password:
1. Set the static IP address for the laptop to be used for programming to the same network IP address as the
NetwaySP3. The default address of the NetwaySP3 is 192.168.168.168, E.I. 192.168.168.200.
2. Connect one end of the network cable to the network jack on the NetwaySP3 and the other to the network
connection of the laptop.
3. Open a browser on the computer and enter "192.168.168.168" into the address bar.
A dialog box Authentication Required will appear requesting both user name and password.
Enter the default values here. Click on the button labeled Log In.
4. The status page of the NetWaySP3 will appear. Click on the tab labeled Network Settings.
This will open the Network Setting screen. In this screen the MAC Address of the NetWaySP3 module will
be found along with the Network Settings and Email Settings.

Network Settings:

In the IP Address Method field select the method that the IP Address for the NetWaySP3 will be obtained
(STATIC or DHCP), then follow the appropriate steps.
Static:
A. IP Address: Enter the IP address assigned to the NetWaySP3 by the network administrator.
B. Subnet Mask: Enter the Subnet of the network.
C. Gateway: Enter the TCP/IP gateway of the network access point (router) being used.
Gateway configuration is required to properly receive emails from the device.
- 4 -
Recommended Altronix SFP Modules:

Technical Specifications:

Description
Three (3) ports PoE+ (30W) or up to two (2) Hi-PoE (60W) ports.
One (1) Gigabit SFP Port.
115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
NetWaySP3B/NetWaySP3WPN: 48-55V UL Listed ITE power supply
Operating Ambient Temperature:
NetWaySP3WP/NetWaySP3WPX:
NetWaySP3X:
NetWaySP3B/NetWaySP3WPN:
Relative Humidity: 85%, +/– 5%
Storage Temperature: – 40ºC to 85ºC (– 40ºF to 185ºF).
Operating Altitude: – 304.8 to 2,000m.
Model
NetWaySP3WP
NetWaySP3WPN
NetWaySP3WPX
NetWaySP3X
NetWaySP3PL
NetWaySP3B
Configuring Units for Network Connection
Please be sure to visit altronix.com for latest
firmware and installation instructions
192.168.168.168
admin
admin
60W: – 40ºC to 75ºC (– 40ºF to 167ºF);
75W: – 40ºC to 70ºC (– 40ºF to 158ºF);
100W: – 40ºC to 55ºC (– 40ºF to 131ºF);
120W: – 40ºC to 45ºC (– 40ºF to 113ºF).
120W: – 40ºC to 50ºC (– 40ºF to 122ºF).
120W: – 40ºC to 75ºC (– 40ºF to 167ºF).
Product Weight
10.32 lbs. (4.68kg)
7.7 lbs. (3.49kg)
15 lbs. (6.8 kg)
6.65 lbs. (3.02 kg)
2.6 lbs. (1.18 kg)
0.25 lbs. (0.11 kg)
Shipping Weight
11.7 lbs. (5.3kg)
10.0 lbs. (4.54kg)
17.5 lbs. (7.9kg)
7.55 lbs. (3.42kg)
4.0 lbs. (1.81kg)
0.75 lbs. (0.34kg)
NetWaySP3 Series
