3. Port Configurations (Fig. 2, pg. 5; Fig. 5b, pg. 10):
Jumper
Jumper Position
PORT 2 30W 30W and Data 30W and Data
PORT 3 30W
PORT 2 60W
PORT 3 60W
4. Connect structured cables from port marked [Port 1] to [Port 4] on NetWay unit to PoE compliant
cameras/edge devices (Fig. 5, pg. 10).
Note: All interconnected devices must be UL Listed.
5. Insert SFP module into port(s) marked [SFP], then connect cable to the SFP module on NetWaySP4B to the
corresponding input of an SFP switch (Fig. 5, pg. 10).
6. Battery Backup (if desired): Connect four (4) 12VDC batteries wired in series to terminals marked
[– BAT +] (Fig. 5, pg. 10), carefully observing polarity.
When use of stand-by batteries is desired, they must be lead acid or gel type.
Note: When batteries are not used, a loss of AC will result in the loss of output voltage.
7. Please ensure that the cover is secured with:
Key lock and screws for NetWaySP4X, security bolt for NetWaySP4WP, NetWaySP4WPN and
NetWaySP4WPX.
Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily
usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM - For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 - For use with Single-Mode Fiber for distances up to 10km.
P1AB2K - For use with Single Strand Single-Mode Fiber for distances up to 2km.
P1GCE - For use with CAT5e or better for distances up to 100m.
Parameter
Number of Ports
Input Power
Requirements
Environmental
Conditions
Weights (approx.)
NetWaySP4 Series Installation Guide
Structured Cable Ports
1 2
– –
Data Only 60W and Data
– –

Recommended Altronix SFP Modules:

Technical Specifications:

Description
Four (4) ports PoE+ (30W) or up to two (2) Hi-PoE (60W) ports.
Two (2) Gigabit SFP Ports.
115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
NetWaySP4B/NetWaySP4WPN: 48-55V UL Listed ITE power supply
Operating Ambient Temperature:
NetWaySP4WP/NetWaySP4WPX:
NetWaySP4X:
NetWaySP4B/NetWaySP4WPN:
Relative Humidity: 85%, +/– 5%
Storage Temperature: – 40ºC to 85ºC (– 40ºF to 185ºF).
Operating Altitude: – 304.8 to 2,000m.
Model
NetWaySP4WP
NetWaySP4WPN
NetWaySP4WPX
NetWaySP4X
NetWaySP4PL
NetWaySP4B
3 4
– –
30W and Data 30W and Data
– –
60W and Data Data Only
60W: – 40ºC to 75ºC (– 40ºF to 167ºF);
75W: – 40ºC to 70ºC (– 40ºF to 158ºF);
100W: – 40ºC to 55ºC (– 40ºF to 131ºF);
120W: – 40ºC to 45ºC (– 40ºF to 113ºF).
120W: – 40ºC to 50ºC (– 40ºF to 122ºF).
120W: – 40ºC to 75ºC (– 40ºF to 167ºF).
Product Weight
10.72 lbs. (4.86 kg)
7.9 lbs. (3.58 kg)
15 lbs. (6.8 kg)
6.85 lbs. (3.11 kg)
2.8 lbs. (1.27 kg)
0.45 lbs. (0.2 kg)
PORT 2
30W 60W
Shipping Weight
12.1 lbs. (5.49 kg)
10.2 lbs. (4.63 kg)
17.5 lbs. (7.9kg)
7.75 lbs. (3.51 kg)
4.2 lbs. (1.9 kg)
1 lbs. (0.45 kg)
Fig. 2
