Fiber Solution
NetWay4EBT3 Series
4-port Hardened 360W 802.3bt
4PPoE Switches
Models Include:
NetWay4EBTWP3
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWay4EBTWPX3
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- NEMA4/4X, IP66 rated Outdoor enclosure.
- Accommodates up to four (4)
12VDC/4AH batteries.
Installation Guide
DOC#: NetWay4EBT3 Rev. 020924
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
NetWay4EBTX3
- 4-port Hardened 802.3bt 4PPoE Switch and
Power Supply/Charger
- NEMA1 rated Indoor enclosure.
NetWay4EBTPL3
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- Backplane version.
More than just power.
Embedded
™
TM
Advertisement
Related Manuals for Altronix NetWay Spectrum NetWay4EBT3 Series
Summary of Contents for Altronix NetWay Spectrum NetWay4EBT3 Series
- Page 1 Embedded ™ Fiber Solution NetWay4EBT3 Series 4-port Hardened 360W 802.3bt 4PPoE Switches Models Include: NetWay4EBTWP3 NetWay4EBTX3 - 4-port Hardened 802.3bt 4PPoE Switch - 4-port Hardened 802.3bt 4PPoE Switch and and Power Supply/Charger Power Supply/Charger - NEMA4/4X, IP66 rated Outdoor enclosure. - NEMA1 rated Indoor enclosure.
- Page 2 Overview: Altronix NetWay4EBT3 Series Hardened 802.3bt 4PPoE Switches are equipped with one (1) 1Gb SFP port and four (4) POE IEEE802.3af/3at/3bt PoE ports rated at 90W each, with a 360W total power. Embedded LINQ Technology enables monitoring, control, and reporting from anywhere over the network.
- Page 3 If batteries are housed in a weather-proof enclosure (NetWay4EBTWP3, NetWay4EBTWPX3), it must be properly ventilated. Use Altronix Vent2 kit. Note: When batteries are not used, a loss of AC will result in the loss of output voltage.
- Page 4 Technical Specifications: Parameter Description Number of Four (4) 10/100/1000 Mbps Ethernet ports rated at 90W each. Ports IEEE 802.3af, 802.3at, 802.3bt compliant. One (1) Gigabit SFP Port. Input Power 115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A. Requirements Operating Ambient Temperature: 360W: –...
- Page 5 Configuring Units for Network Connection –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Please be sure to visit altronix.com for latest firmware and installation instructions –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Factory Default Settings • IP Address: 192.168.168.168 • User Name: admin • Password: admin 1. Set the static IP address for the laptop to be used for programming to the same network IP address as the Netway4EBTB.
- Page 6 It is important to plan how you will setup your devices for each vLan. Configuring vLan on the Altronix Netway4EBT3 Series Switch: 1. Ensure Laptop or PC being used to program the vLan settings is on a port that will be assigned to your first vLan configuration.
- Page 7 Continue holding the button until the LEDs on board go Master Reset through the start up cycle, then release the button. 3. The unit returns to the original factory settings. Altronix Corp. Brooklyn, NY US Netway4EBT www.altronix.com Netway4EBT3 Series Installation Guide...
- Page 8 This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 and PMK2 outdoor pole mount kits are designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in models WP1, WP2, WP3 and WP4 NEMA rated enclosures. PMK1 and PMK2 can be mounted on 2”...
- Page 9 NetWay4EBTWP3 Mechanical Drawing and Dimensions (H x W x D approx.): 13.31” x 11.31” x 5.59” (338.1mm x 287.3mm x 142mm) FRONT VIEW RIGHT SIDE VIEW 11.31” (287.3mm) 3.96” (100.6mm) FRONT VIEW COVER REMOVED END VIEW 10.75” (273.1mm) 10.00” (254mm) STAINLESS STEEL PIANO HINGE 8.25”...
- Page 10 NetWay4EBTWPX3 Mechanical Drawing and Dimensions (H x W x D approx.): 17.53” x 15.3” x 6.67” (445.3mm x 388.6mm x 169.4mm) FRONT VIEW RIGHT SIDE VIEW 1.67” (42.4mm) 15.3” (388.6mm) 5.00” (127mm) 316 STAINLESS STEEL PADLOCK LATCH FRONT VIEW COVER REMOVED ATTACHED WITH RIVETS.
- Page 11 NetWay4EBTX3 Mechanical Drawing and Dimensions (H x W x D approx.): 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm) 1.40” 1.40” 4.85” (123.2mm) 4.85” (123.2mm) (35.6mm) (35.6mm) 1.20” (30.5mm) 0.75” 0.75” 12.5” (317.5mm) 1.20” 1.20” (19.1mm) (19.1mm) (30.5mm) (30.5mm) 11.0”...
- Page 12 10.75” x 8.875” x 2.375” (273.1mm x 225.4mm x 60.3mm) 8.875” (225.4mm) 8.25” (209.5mm) 0.25” (6.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
