8-Port Ethernet over Fiber
PoE+ Hardened Switches
Installation Guide
Models include:
NetWaySP8WP
- Includes Fiber Optic SFP 1G Link,
8-port PoE+ switch and power supply.
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWaySP8WPX
- Includes Fiber Optic SFP 1G Link,
8-port PoE+ switch and power supply.
- NEMA4/4X, IP66 rated Outdoor enclosure.
- Accommodates up to four (4)
12VDC/4AH batteries.
NetWaySP8X
- Includes Fiber Optic SFP 1G Link,
8-port PoE+ switch and power supply.
- NEMA1 rated Indoor enclosure.
I.T.E. 43KC
DOC#: NetWaySP8 Rev. 032117
NetWaySP8WPN
- Includes Fiber Optic SFP 1G Link and
8-port PoE+ switch
(uses external power supply).
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWaySP8PL
- Includes Fiber Optic SFP 1G Link,
8-port PoE+ switch and power supply.
- Backplane version.
NetWaySP8B
- Fiber Optic SFP 1G Link and
8-port PoE+ switch
- Board only.
More than just power.
Embedded
™
TM
Advertisement
Table of Contents
Related Manuals for Altronix NetWaySP8WP
Summary of Contents for Altronix NetWaySP8WP
- Page 1 Embedded ™ 8-Port Ethernet over Fiber PoE+ Hardened Switches Installation Guide Models include: NetWaySP8WP NetWaySP8WPN - Includes Fiber Optic SFP 1G Link and - Includes Fiber Optic SFP 1G Link, 8-port PoE+ switch 8-port PoE+ switch and power supply. (uses external power supply).
-
Page 2: Agency Listings
Overview: Altronix NetWay Indoor/Outdoor Ethernet over Fiber PoE Hardened Switches provide two (2) 1Gb SFP ports and eight (8) PoE+ (30W) ports or up to two (2) Hi-PoE (60W) ports, passing data and power to PoE/PoE+ compliant devices. Cameras/edge devices may be located up to 100m from the unit. Features also include an integral battery charger for applications requiring backup and embedded LINQ Technology to monitor, control, and report power and diagnostics from anywhere. -
Page 3: Installation Instructions
Pole Mount: Refer to Figs. 6 - 10, pg. 8. NetWaySP8WPX only: In order to properly mount NetWaySP8WPX on a pole using Altronix PMK1, additional holes need to be drilled in the enclosure’s flanges, so the distance between those holes is 10”. -
Page 4: Technical Specifications
NetWaySP8WPX. Recommended Altronix SFP Modules: Altronix P1MM and P1SM10 are hot-pluggable SFP fiber transceiver modules and are readily usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates. P1MM - For use with Multi-Mode Fiber for distances up to 550m. -
Page 5: Network Settings
3. Open a browser on the computer and enter “192.168.168.168” into the address bar. A dialog box Authentication Required will appear requesting both user name and password. Enter the default values here. Click on the button labeled Log In. 4. The status page of the NetWaySP8 will appear. Click on the tab labeled Network Settings. This will open the Network Setting screen. - Page 6 1000 PORT5 PORT6 1000 SFP2 PORT7 PORT8 PORT 3 PORT 4 (1G) ALOS SFP Port PORT 5 PORT 6 (1G) Altronix Corp. Brooklyn, NY US www.altronix.com Factory Reset PORT 7 PORT 8 PoE5 PoE6 PoE7 PoE8 Input: 48V-56VDC 5A 250VA...
- Page 7 1000 PORT5 PORT6 1000 SFP2 PORT7 PORT8 ALOS PORT 3 PORT 4 (1G) SFP Port PORT 5 PORT 6 (1G) Altronix Corp. Brooklyn, NY US www.altronix.com Factory Reset PORT 7 PORT 8 PoE5 PoE6 PoE7 PoE8 Input: 48V-56VDC NetWaySP4 Series...
-
Page 8: Wall Mount Installation
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 is intended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures. Brackets are designed for use with the Wormgear Quick Release Straps (two included). - Page 9 NetWaySP8X Mechanical Drawing and Dimensions (H x W x D approx.): 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm) 1.40” 4.85” 4.85” 1.40” (36mm) (123mm) (123mm) (36mm) 1.20” (31mm) 3.25” (83mm) 12.5” (318mm) 1.20” 1.20” 0.75” 0.75” (31mm) 11.0”...
- Page 10 NetWaySP8PL Mechanical Drawing and Dimensions (H x W x D approx.): 10.75” x 8.875” x 2.375” (273.1mm x 225.4mm x 60.3mm) 8.875” (225.4mm) 8.25” (209.5mm) 0.25” (6.4mm) 10.25” 10.75” (260.3mm) (273.1mm) - 10 - NetWaySP4 Series...
- Page 11 NetWaySP8WP and NetWaySP8WPN Mechanical Drawing and Dimensions (H x W x D approx.): 13.31” x 11.31” x 5.59” (338.1mm x 287.3mm x 142mm) - 11 - NetWaySP4 Series...
- Page 12 17.53” x 15.3” x 6.67” (445.3mm x 388.6mm x 169.4mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IINetWaySP8 Series...
