Altronix NetWay4E1 Series Installation Manual page 2

Altronix NetWay4E1 Series Hardened PoE Switches are equipped with one (1) 1Gb SFP port and four (4) PoE
IEEE802.3af/3at/ & Hi PoE ports rated at 30W each, limited to total power of the power supply employed.
Agency Listings:
• CE European Conformity.
Input:
• 115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
• NetWay4E1B/NetWay4E1WPN:
48-56V UL Listed ITE power supply.
Power Output:
• Four (4) 10/100/1000 Mbps Ethernet ports rated at
30W each (limited to 120W total power).
• NetWay4E1B/NetWay4E1WPN:
Four (4) 10/100/1000 Mbps Ethernet ports rated at
30W each (depending on the power supply
employed).
• IEEE 802.3af, 802.3at compliant.
SFP Ports:
• One (1) Gigabit SFP port.
Ethernet Ports:
• Four (4) 10/100/1000 Mbps ports.
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5e or higher structured cable.
• Speed: 10/100/1000 Mbps, half/full duplex,
auto negotiation.
Indicators (LED):
• Individual PoE On LEDs for each port.
• Individual IP Link status, 100/1000 Base-T/active
LEDs for each port.
• ALOS LED indicates fiber connection for SFP port.
• Heartbeat LED indicates proper operation of the unit.
- 2 -
Overview:
Features:
Mechanical:
NetWay4E1B:
• Dimensions (L x W x D approx.):
6.25" x 4.5" x 1.25"
(158.8mm x 142.9mm x 31.8mm).
NetWay4E1PL
• Dimensions (H x W x D approx.):
10.75" x 8.875" x 2.375"
(273.1mm x 225.4mm x 60.3mm).
NetWay4E1WP, NetWay4E1WPN:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
13.31" x 11.31" x 5.59"
(338.1mm x 287.3mm x 142mm).
NetWay4E1WPX:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Accommodates four (4) 12VDC/4AH batteries
(48V of backup).
• Dimensions (H x W x D approx.):
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm).
NetWay4E1X:
• Dimensions (H x W x D approx.):
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 83mm).
