Technical Specifications; Typical Applications Drawings - Altronix netway SPECTRUM NetWaySP41BT3 Series Installation Manual

Parameter Description
Number of
Four (4) 10/100/1000 Mbps Ethernet ports rated at 90W each.
Ports
IEEE 802.3af, 802.3at, 802.3bt compliant. Two (2) Gigabit SFP Ports.
Input Power
115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A.
Requirements
Operating Ambient Temperature:
Environmental
Conditions Storage Temperature: – 30ºC to 85ºC (– 22ºF to 185ºF)
Relative Humidity:
Operating Altitude:
Weights
(approx.)
Fig. 1
NetWaySP41BT3 Series Installation Guide

Technical Specifications:

360W: – 30ºC to 70ºC (– 22ºF to 158ºF)
240W: – 30ºC to 75ºC (– 22ºF to 167ºF)
85%, +/– 5%
– 304.8 to 2,000m
Model
NetWaySP41BTWP3
NetWaySP41BTWPX3
NetWaySP41X3
NetWaySP41PL3
Typical Applications:
To 24V Stand-by
Batteries
L G N
115/230VAC
Input
Product Weight
10.5 lb. (4.76 kg)
15 lb. (6.8 kg)
6.85 lb. (3.11 kg)
2.6 lb. (1.18 kg)
IEEE 802.3bt
PoE/PoE+/Hi-PoE
Device
Fiber to the next
Netway Spectrum
Hardened PoE Switch
Shipping Weight
11.9 lb. (5.4 kg)
17.5 lb. (7.9kg)
7.75 lb. (3.51 kg)
4.0 lb. (1.81kg)
IEEE 802.3bt
PoE/PoE+/Hi-PoE
Device
PoE/PoE+,
Hi-PoE or
BT Device
Fiber to Switch
- 5 -
