4 . Connect structured cables from port marked [Port 1] to [Port 4] on NetWay unit to PoE compliant
cameras/edge devices (Fig. 5, pg. 9) .
Note: All interconnected devices must be UL Listed .
5 . Insert SFP module into port(s) marked [SFP], then connect cable to the SFP module on NetWaySP4B to the
corresponding input of an SFP switch (Fig. 5, pg. 9) .
6 . Battery Backup (if desired): Connect four (4) 12VDC batteries wired in series to terminals marked
[– BAT +] (Fig. 5, pg. 9), carefully observing polarity .
When use of stand-by batteries is desired, they must be lead acid or gel type .
Note: When batteries are not used, a loss of AC will result in the loss of output voltage .
7 . Please ensure that the cover is secured with:
Key lock and screws for NetWaySP4X, security bolt for NetWaySP4WP, NetWaySP4WPN and
NetWaySP4WPX.
Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily
usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates .
P1MM - For use with Multi-Mode Fiber for distances up to 550m .
P1SM10 - For use with Single-Mode Fiber for distances up to 10km .
P1AB2K - For use with Single Strand Single-Mode Fiber for distances up to 2km .
P1GCE - For use with CAT5e or better for distances up to 100m .
Parameter
Number of Ports
Input Power
Requirements
Environmental
Conditions
Weights (approx.)

Factory Default Settings

• IP Address:
• User Name:
• Password:
1 . Set the static IP address for the laptop to be used for programming to the same network IP address as the
NetwaySP4 . The default address of the NetwaySP4 is 192 .168 .168 .168, E .I . 192 .168 .168 .200 .
2 . Connect one end of the network cable to the network jack on the NetwaySP4 and the other to the network
connection of the laptop .
3 . Open a browser on the computer and enter "192 .168 .168 .168" into the address bar .
A dialog box Authentication Required will appear requesting both user name and password .
Enter the default values here . Click on the button labeled Log In .
4 . The status page of the NetWaySP4 will appear . Click on the tab labeled Network Settings .
This will open the Network Setting screen . In this screen the MAC Address of the NetWaySP4 module will
be found along with the Network Settings and Email Settings .
NetWaySP4 Series

Recommended Altronix SFP Modules:

Technical Specifications:

Description
Four (4) ports PoE+ (30W) or up to two (2) Hi-PoE (60W) ports .
Two (2) Gigabit SFP Ports .
115VAC, 60Hz, 2 .5A or 230VAC, 50/60Hz, 1 .3A .
NetWaySP4B/NetWaySP4WPN: 48-55V UL Listed ITE power supply
Operating Ambient Temperature:
NetWaySP4WP/NetWaySP4WPX:
NetWaySP4X:
NetWaySP4B/NetWaySP4WPN:
Relative Humidity: 85%, +/- 5%
Storage Temperature: -40ºC to 85ºC (-40ºF to 185ºF) .
Operating Altitude: -304 .8 to 2,000m .
Model
NetWaySP4WP
NetWaySP4WPN
NetWaySP4WPX
NetWaySP4X
NetWaySP4PL
NetWaySP4B

Configuring Units for Network Connection

Please be sure to visit altronix.com for latest
firmware and installation instructions
192 .168 .168 .168
admin
admin
60W: -40ºC to 75ºC (-40ºF to 167ºF);
75W: -40ºC to 70ºC (-40ºF to 158ºF);
100W: -40ºC to 55ºC (-40ºF to 131ºF);
120W: -40ºC to 45ºC (-40ºF to 113ºF) .
120W: -40ºC to 50ºC (-40ºF to 122ºF) .
120W: -40ºC to 75ºC (-40ºF to 167ºF) .
Product Weight
10 .72 lbs . (4 .86 kg)
7 .9 lbs . (3 .58 kg)
15 lbs . (6 .8 kg)
6 .85 lbs . (3 .11 kg)
2 .8 lbs . (1 .27 kg)
0 .45 lbs . (0 .2 kg)
Shipping Weight
12 .1 lbs . (5 .49 kg)
10 .2 lbs . (4 .63 kg)
17 .5 lbs . (7 .9kg)
7 .75 lbs . (3 .51 kg)
4 .2 lbs . (1 .9 kg)
1 lbs . (0 .45 kg)
