4. Connect structured cables from port marked [Port 1] to [Port 8] on NetWay unit to PoE-compliant cameras/
edge devices (Fig. 3, pg. 6). Note: All interconnected devices must be UL Listed.
5. Insert SFP module into port(s) marked [SFP], then connect cable to the SFP module on NetWaySP8B to the
corresponding input of an SFP switch (Fig. 3, pg. 6).
6. Battery Backup (if desired): Connect four (4) 12VDC batteries wired in series to terminals marked
[+ BAT –] (Fig. 3, pg. 6), carefully observing polarity.
When use of stand-by batteries is desired, they must be lead acid or gel type.
Note: When batteries are not used, a loss of AC will result in the loss of output voltage.
7. Please ensure that the cover is secured with:
Key lock and screws for NetWaySP8X, security bolt for NetWaySP8WP, NetWaySP8WPN and
NetWaySP8WPX.
Altronix P1MM and P1SM10 are hot-pluggable SFP fiber transceiver modules and are readily usable with all
Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM - For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 - For use with Single-Mode Fiber for distances up to 10km.
Parameter
Number of Ports
Input Power
Requirements
Environmental
Conditions
Weights (approx.)
Please be sure to visit altronix.com for latest firmware and

Factory Default Settings

• IP Address:
• User Name:
• Password:
1. Set the static IP address for the laptop to be used for programming to the same network IP address as the
NetwaySP8. The default address of the NetwaySP8 is 192.168.168.168, E.I. 192.168.168.200.
2. Connect one end of the network cable to the network jack on the NetwaySP8 and the other to the network
connection of the laptop.
- 4 -
Recommended Altronix SFP Modules:

Technical Specifications:

Description
Eight (8) ports PoE+ (30W) or up to two (2) Hi-PoE (60W) ports.
Two (2) Gigabit SFP Ports.
115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
NetWaySP8B/NetWaySP8WPN: 48-55V UL Listed ITE power supply
Operating Ambient Temperature:
NetWaySP8WP/NetWaySP8WPX:
NetWaySP8X:
NetWaySP8B/NetWaySP8WPN:
Relative Humidity: 85%, +/- 5%
Storage Temperature: -40ºC to 85ºC (-40ºF to 185ºF).
Operating Altitude: -304.8 to 2,000m.
Model
NetWaySP8WP
NetWaySP8WPN
NetWaySP8WPX
NetWaySP8X
NetWaySP8PL
NetWaySP8B
Configuring Units for Network Connection
installation instructions
192.168.168.168
admin
admin
60W: -40ºC to 75ºC (-40ºF to 167ºF);
75W: -40ºC to 70ºC (-40ºF to 158ºF);
100W: -40ºC to 55ºC (-40ºF to 131ºF);
115W: -40ºC to 45ºC (-40ºF to 113ºF).
115W: -40ºC to 50ºC (-40ºF to 122ºF).
115W: -40ºC to 75ºC (-40ºF to 167ºF).
Product Weight
10.72 lbs. (4.86 kg)
7.9 lbs. (3.58 kg)
15 lbs. (6.8 kg)
6.85 lbs. (3.11 kg)
2.8 lbs. (1.27 kg)
0.45 lbs. (0.2 kg)
Shipping Weight
12.1 lbs. (5.49 kg)
10.2 lbs. (4.63 kg)
17.5 lbs. (7.9kg)
7.75 lbs. (3.51 kg)
4.2 lbs. (1.9 kg)
1 lbs. (0.45 kg)
