Fiber Solution
NetWay4E1L Series
Hardened Ethernet over Fiber PoE+ Switch
with Optimized Lithium Iron Phosphate
Battery Charger
Models Include:
NetWay4E1LWP
- Fiber Optic SFP 1G Link,
4-port PoE+ switch and power supply.
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWay4E1LWPX
- Fiber Optic SFP 1G Link,
4-port PoE+ switch and power supply.
- NEMA4/4X, IP66 rated Outdoor enclosure.
- Accommodates one (1) 12V LiFePO 4 battery.
Installation Guide
DOC#: NetWay4E1L Rev. 062822
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
NetWay4E1LX
- Fiber Optic SFP 1G Link,
4-port PoE+ switch and power supply.
- NEMA1 rated Indoor enclosure.
NetWay4E1LPL
- Fiber Optic SFP 1G Link,
4-port PoE+ switch and power supply.
- Backplane version.
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix NetWay4E1L Series
Summary of Contents for Altronix NetWay4E1L Series
- Page 1 Fiber Solution NetWay4E1L Series Hardened Ethernet over Fiber PoE+ Switch with Optimized Lithium Iron Phosphate Battery Charger Models Include: NetWay4E1LWP NetWay4E1LX - Fiber Optic SFP 1G Link, - Fiber Optic SFP 1G Link, 4-port PoE+ switch and power supply. 4-port PoE+ switch and power supply.
-
Page 2: Table Of Contents
Recommended Altronix SFP Modules ........ -
Page 3: Overview
Overview: Altronix NetWay Spectrum Indoor/Outdoor Hardened Ethernet over Fiber PoE+ Switches with Optimized Lithium Iron Phosphate Battery Charger provide a 1Gb SFP port and four (4) POE IEEE802.3af/3at & Hi POE ports, passing data and power to PoE/PoE+ compliant devices. These units are designed to support a single 12V LiFePO 4 (Lithium Iron Phosphate) battery for high storage and charge/discharge cycle life reliability (only a single battery is needed). -
Page 4: Enclosure/Backplane Mounting Instructions
(Lithium Iron Phosphate) battery to terminals marked [+ BAT –] (Fig. 2, pg. 4), carefully observing polarity. Stand-by Switch Use Altronix BTL125 12V/4.5AH Lithium Iron Phosphate battery. LiFePO 4 Board Battery Note: LiFePO 4 batteries have a restricted temperature range. -
Page 5: Technical Specifications
Recommended Altronix SFP Modules: Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates. P1MM - For use with Multi-Mode Fiber for distances up to 550m. -
Page 6: Wall Mount Installation
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK outdoor pole mount kit is designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in models WP1, WP2, WP3 and WP4 NEMA rated enclosures. PMK can be mounted on 2” to 8” (50.8mm to 203.2mm) diameter round or 5”... -
Page 7: Mechanical Drawings And Dimensions
(30.5mm) 0.75” 0.75” 12.5” (317.5mm) 1.20” 1.20” (19.1mm) (19.1mm) (30.5mm) (30.5mm) 11.0” (279.4mm) 0.9375” (23.8mm) 1.40” 1.40” (35.6mm) (35.6mm) 0.9375” (23.8mm) 3.25” (82.6mm) 3.25” (82.6mm) 1.0” (25.4mm) 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) NetWay4E1L Series Installation Guide - 7 -... - Page 8 NetWay4E1LPL Mechanical Drawing and Dimensions (H x W x D approx.): 10.75” x 8.875” x 2.375” (273.1mm x 225.4mm x 60.3mm) 8.875” (225.4mm) 8.25” (209.5mm) 0.25” (6.4mm) - 8 - NetWay4E1L Series Installation Guide...
- Page 9 PADLOCK LATCH ATTACHED WITH RIVETS (Ø 0.375” (9.5mm) PADLOCK EYE) 8.00” (203.2mm) Ø 0.32 (8.1mm) MOUNTING HOLE TYP. 4 PLACES 10-32 X 0.375” (9.5mm) BRASS INSERT (X4) 10-32 X 0.25” (6.4mm) BRASS INSERT (X2) NetWay4E1L Series Installation Guide - 9 -...
- Page 10 ATTACHED WITH RIVETS. Ø 0.375 PADLOCK EYE 14.54” (369.3mm) 14.00” (355.6mm) SECTION A-A 12.23” (310.6mm) 0.125” (3.2mm) MOUNTING PLATE END VIEW Ø 0.32” (8.1mm) WALL MOUNTING HOLE X 4 10-32 X 0.250 BRASS INSERT 4 PLCS. 12.00” (304.8mm) - 10 - NetWay4E1L Series Installation Guide...
- Page 11 Notes: NetWay4E1L Series Installation Guide - 11 -...
- Page 12 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IINetWay4E1L Series F28V - 12 - NetWay4E1L Series Installation Guide...
