Parameter Description
Number of
Four (4) 10/100/1000 Mbps Ethernet ports rated at 90W each.
Ports
IEEE 802.3af, 802.3at, 802.3bt compliant. Two (2) Gigabit SFP Ports.
Input Power
115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A.
Requirements
Operating Ambient Temperature:
Environmental
Conditions Storage Temperature: – 30ºC to 85ºC (– 22ºF to 185ºF)
Relative Humidity:
Operating Altitude:
Weights
(approx.)
Fig. 1
- 4 -

Technical Specifications:

360W: – 30ºC to 70ºC (– 22ºF to 158ºF)
240W: – 30ºC to 75ºC (– 22ºF to 167ºF)
85%, +/– 5%
– 304.8 to 2,000m
Model
NetWaySP4BTWP3
NetWaySP4BTWPX3
NetWaySP4X3
NetWaySP4PL3

Typical Applications:

To 24V Stand-by
Batteries
L G N
115/230VAC
Input
Product Weight
10.5 lb. (4.76 kg)
15 lb. (6.8 kg)
6.85 lb. (3.11 kg)
2.6 lb. (1.18 kg)
IEEE 802.3bt
PoE/PoE+/Hi-PoE
Device
Factory Reset
USB Port for
Configuring
Fiber to the next
Netway Spectrum
Hardened PoE Switch
Shipping Weight
11.9 lb. (5.4 kg)
17.5 lb. (7.9kg)
7.75 lb. (3.51 kg)
4.0 lb. (1.81kg)
IEEE 802.3bt
PoE/PoE+/Hi-PoE
Device
Fig. 1a
PoE/PoE+,
Hi-PoE or
BT Device
Fiber to Switch
