Power over the Ethernet
NetWay5BT Series
5-Port Hardened 802.3bt 4PPoE Switches
Models Include:
NetWay5BTWP
- 5-port Hardened 802.3bt 4PPoE Switch with
Power Supply/Charger
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWay5BTWPX
- 5-port Hardened 802.3bt 4PPoE Switch with
Power Supply/Charger
- NEMA4/4X, IP66 rated Outdoor enclosure.
- Accommodates up to four (4)
12VDC/4AH batteries.
NetWay5BTWPN
- 5-port Hardened 802.3bt 4PPoE Switch
- NEMA4/4X rated outdoor enclosure
Installation Guide
Rev. 030424
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
NetWay5BTX
- 5-port Hardened 802.3bt 4PPoE Switch with
Power Supply/Charger
- NEMA1 rated Indoor enclosure.
NetWay5BTPL
- 5-port Hardened 802.3bt 4PPoE Switch with
Power Supply/Charger
- Backplane version.
NetWay5BT
- 5-port Hardened 802.3bt 4PPoE Switch
- Board Only
More than just power.
TM

Advertisement

loading
Need help?

Need help?

Do you have a question about the NetWay5BT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Altronix NetWay5BT Series

Summary of Contents for Altronix NetWay5BT Series

  • Page 1 Power over the Ethernet NetWay5BT Series 5-Port Hardened 802.3bt 4PPoE Switches Models Include: NetWay5BTWP NetWay5BTX - 5-port Hardened 802.3bt 4PPoE Switch with - 5-port Hardened 802.3bt 4PPoE Switch with Power Supply/Charger Power Supply/Charger - NEMA4/4X, IP66 rated Outdoor enclosure. - NEMA1 rated Indoor enclosure.

  • Page 2: Installation Instructions

    4. Connect a Data source to the [Data Input] RJ45 jack (Fig. 1b, pg. 4). 5. Connect Access Control boards, Altronix LINQ units or other IP devices to the [Port 1 - Port 4] RJ45 jacks (Fig. 1c, pg. 4). Refer to the corresponding Installation Guides for details.

  • Page 3: Power Connection

    1. Connect a Data source to the [Data Input] RJ45 jack (Fig. 1b, pg. 4). 2. Connect Access Control boards, Altronix LINQ units or other IP devices to the [Port 1 - Port 4] RJ45 jacks (Fig. 1c, pg. 4). Refer to the corresponding Installation Guides for details.
  • Page 4 Fig. 1 - NetWay5BT Board Configulration +54V DATA INPUT PORT1 PORT2 PORT3 PORT4 DATA IN Netway5PBT LED2 LED4 LED6 LED8 LED11 Netway5PBTQ LED1 LED3 LED5 LED7 LED10 Altronix Corp. Brooklyn, NY US www.altronix.com - 4 - NetWay5PBT Series Installation Guide...

  • Page 5: Technical Specifications

    Terminal and Port Identification: Terminal/Port Function/Description Legend Connect a 48-56V UL Listed power source to these terminals carefully observing polarity. GND +54V Factory connected to power supply in NetWay5BTWP, NetWay5BTPL, NetWay5BTWPX, NetWay5BTX (Fig. 1a, pg. 4) Data Input Can be used as a Data Uplink (Fig. 1b, pg. 4). Port 1 - Port 4 Data and PoE/PoE+ (IEEE802.3af/3at/3bt compliant) ports (Fig.

  • Page 6: Typical Application

    LED7 LED10 LEDs Altronix Corp. Brooklyn, NY US www.altronix.com To Networked Access Controllers, Devices & Cameras and/or Altronix LINQ Series Ethernet connections *NetWay5BTWP, NetWay5BTWPX, NetWay5BTPL and NetWay5BTX are factory connected to Power Supply - 6 - NetWay5PBT Series Installation Guide...

  • Page 7: Wall Mount Installation

    This installation should be made by qualified service personnel. This product contains no serviceable parts. Pole mount kits are intended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures. Brackets are designed for use with the Wormgear Quick Release Straps (two included).
  • Page 8 NetWay5BTWPN Mechanical Drawing and Dimensions (H x W x D approx.): 9.5” x 7.32” x 4.92” (241.3mm x 185.9mm x 125mm) 1.38” 7.32” (185.9mm) 3.54” (89.9mm) (35.1mm) 316 Stainless Steel Padlock Latch Attached 0.375” (9.5mm) Padlock Eye 6.75” (171.5mm) 6.0” (152.4mm) 4.25”...
  • Page 9 NetWay5BTWP Mechanical Drawing and Dimensions (H x W x D approx.): 13.31” x 11.31” x 5.59” (338.1mm x 287.3mm x 142mm) FRONT VIEW RIGHT SIDE VIEW 11.31” (287.3mm) 3.96” (100.6mm) FRONT VIEW COVER REMOVED END VIEW 10.75” (273.1mm) 10.00” (254mm) STAINLESS STEEL PIANO HINGE 8.25”...
  • Page 10 NetWay5BTWPX Mechanical Drawing and Dimensions (H x W x D approx.): 17.53” x 15.3” x 6.67” (445.3mm x 388.6mm x 169.4mm) FRONT VIEW RIGHT SIDE VIEW 1.67” (42.4mm) 15.3” (388.6mm) 5.00” (127mm) 316 STAINLESS STEEL PADLOCK LATCH FRONT VIEW COVER REMOVED ATTACHED WITH RIVETS.
  • Page 11 NetWay5BTX Mechanical Drawing and Dimensions (H x W x D approx.): 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm) 1.40” 1.40” 4.85” (123.2mm) 4.85” (123.2mm) (35.6mm) (35.6mm) 1.20” (30.5mm) 0.75” 0.75” 12.5” (317.5mm) 1.20” 1.20” (19.1mm) (19.1mm) (30.5mm) (30.5mm) 11.0”...
  • Page 12 10.75” x 8.875” x 2.375” (273.1mm x 225.4mm x 60.3mm) 8.875” (225.4mm) 8.25” (209.5mm) 0.25” (6.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
