VLT® FC 100 LonWorks
5.6 Net w or k Var iable Descr ipt ion - VSD Pr ofile - Configur at ion
5.6.1 Max Mot or Speed [ % ]
Var iable SNVT
nam e: t ype:
nciMaxSpeed SNVT_lev_percent
This variable configures the maximum motor speed in % and associates it with par. 4-13
The value is entered as a percent of nominal speed, as defined by the Nominal Speed (nciNmlSpeed) configuration value.
For more information on reference scaling, please refer to the
parameter access command.
5.6.2 Min Mot or Speed [ % ]
Var iable SNVT
nam e: t ype:
nciMinSpeed SNVT_lev_percent
This variable configures the minimum motor speed in % and associates it with par. 4-11
The value is entered as a percent of nominal speed, as defined by the Nominal Speed (nciNmlSpeed) configuration value.
For more information on reference scaling, please refer to the
5.6.3 Nom Mot or Speed [ RPM]
Var iable SNVT
nam e: t ype:
nciNmlSpeed SNVT_rpm
This variable configures the nominal motor speed in RPM and associates it with par. 1-25
NB!
Please note that this variable can be adjusted only while the frequency converter is stopped.
If a value lower than 10 RPM is entered, nciNmlSpeed will be set to 10 RPM.
5.6.4 Nom inal Mot or Fr equency [ Hz]
Var iable SNVT
nam e: t ype:
nciNmlFreq SNVT_freq_hz
This variable configures the nominal motor frequency and associates it with par. 1-23
NB!
Please note that this variable can be adjusted only while the frequency converter is stopped.
If a value lower than 20 Hz is entered, nciNmlFreq will be set to 20 Hz.
Def ault value:
100 %
How to Control the FC 100
Def ault value:
0 %
How to Control the FC 100
Def ault value:
1420 RPM
Def ault value:
50 Hz
Motor Frequency
®
MG.11.E2.02 - VLT is a registered Danfoss trademark
5 Configuration of the system
Min value:
0 %
Motor Speed High Limit [RPM] (par. 4-14 in Hz mode).
section. If a value higher than 163.830% is requested, use the
Min value:
0 %
Motor Speed Low Limit [RPM] (par. 4-12 in Hz mode).
section.
Min value:
10 RPM
Motor Nominal Speed
.
Min value:
20 Hz
.
Max value:
163.830 %
5
Max value:
163.830 %
Max value:
65,534 RPM
Max value:
100 Hz
37
