VLT® FC 100 LonWorks
Out put var iables
Var iable f unct ion Var iable nam e
Status word nvoStatusword
Drive output [%] nvoOutputPcnt
Drive output [Hz] nvoOutputHz
kWh counter nvoDrvEnrg
DC Link Voltage nvoDCVoltage
Motor thermal nvoTempMtr
Inverter Thermal nvoTempInvrtr
Closed loop feedback nvoFeedback
Fanbelt broken nvoBrokenBelt
Alarm flag nvoAlarm
Warning flag nvoWarning
Alarm word nvoAlarmword
Warning word nvoWarningword
Extended statusword nvoExtendedStatusword
Digital inputs nvoDigitInput
Analog Input (53) nvoAnIn1
Analog Input (54) nvoAnIn2
Analog Input (X30/11) nvo101AnIn1
Analog Input (X30/12) nvo101AnIn2
Analog Input (X42/1) nvo109AnIn1
Analog Input (X42/3) nvo109AnIn2
Analog Input (X42/5) nvo109AnIn3
ECB option status nvoECBstatus
Parameter access cmd. nvoParamResponse
SNVT t ype
SNVT_state
SNVT_lev_percent
SNVT_freq_hz
SNVT_elec_kwh_l
SNVT_volt
SNVT_lev_cont
SNVT_lev_cont
SNVT_count_inc_f
SNVT_switch
SNVT_switch
SNVT_switch
SNVT_state_64
SNVT_state_64
SNVT_state_64
SNVT_state_64
SNVT_volt/SNVT_amp_mil/SNVT_lev_percent
SNVT_volt/SNVT_amp_mil/SNVT_lev_percent
SNVT_volt/SNVT_lev_percent
SNVT_volt/SNVT_lev_percent
SNVT_volt/SNVT_temp_p/SNVT_lev_percent
SNVT_volt/SNVT_temp_p/SNVT_lev_percent
SNVT_volt/SNVT_temp_p/SNVT_lev_percent
SNVT_state
UNVT_param_response
®
MG.11.E2.02 - VLT is a registered Danfoss trademark
5 Configuration of the system
Pr of ile FC 100 par .
FC VSD 16-03
FC VSD 16-05
FC VSD 16-13
FC VSD 15-02
FC VSD 16-30
FC VSD 16-18
FC VSD 16-35
FC VSD 16-52
FC VSD 16-93
FC VSD 16-90
FC VSD 16-03
FC VSD 16-90 + 16-91
FC VSD 16-92 + 16-93
FC VSD 16-94 + 16-95
FC VSD 16-60
FC VSD 16-62
FC VSD 16-64
FC VSD 16-75
FC VSD 16-76
FC VSD 18-30
FC VSD 18-31
FC VSD 18-32
FC VSD 31-10
FC VSD -
