VLT® FC 100 LonWorks

9.3 Ref erence Scaling - Ex am ples

9.3.1 Ref er ence Scaling - Open Loop

Exam ple:

Minimum Reference

par. 3-02

par. 3-03

Maximum Reference

Reference send = 1500 hex (5376 dec)

Out put :

The output can be calculated as:

Reference (decimal) * (par.3−03 − par.3−02)

16384

5376 * (1500 − 100)

+ 100 =

559 RPM

16384

= 100 RPM

= 1500 RPM

+ par.3 − 02 =

MG.11.E2.02 - VLT

is a registered Danfoss trademark

9 Troubleshooting
