5 Configuration of the system
5.3 VSD 6010 Pr of ile
5.3.1 I nt r oduct ion
Variable Speed Drive 6010
The
It describes how to control a variable speed frequency converter.
For example, an air handling unit controller that sends messages to facilitate control of the start/stop and speed reference of the VSD. The VSD will deliver
messages such as the actual frequency converter speed and output current to the controller, operating interfaces and energy management systems.
5
5.3.2 I nput Var iables
Variable funct ion
Drive speed setpoint
5.3.3 Out put Var iables
Variable funct ion
Drive speed
Output current
Output voltage
Output power
Running hours
34
profile is a LonMark standardized functional profile.
Var iable nam e
nviDrvSpeedStpt
Var iable nam e SNVT t ype
nvoDrvSpeed SNVT_lev_percent
nvoDrvCurnt SNVT_amp
nvoDrvVolt SNVT_volt
nvoDrvPwr SNVT_power_kilo
nvoDrvRunHours SNVT_time_hour
MG.11.E2.02 - VLT
SNVT t ype Pr of ile
SNVT_switch VSD 6010
Pr of ile
VSD 6010
VSD 6010
VSD 6010
VSD 6010
VSD 6010
®
is a registered Danfoss trademark
VLT® FC 100 LonWorks
FC 100 par am et er
CTW / Reference
FC 100 par am et er
16-05
16-14
16-12
16-10
15-01
