VLT® FC 100 LonWorks
5.3.4 Conf igur at ion Pr oper t ies ( nci)
Var iable funct ion
Max. motor speed [%]
Min. motor speed [%]
Nom. motor speed [RPM]
Nom. motor frequency [Hz]
Min. ramp-up time [s]
Min. ramp-down time [s]
Heartbeat time [s]
A range of network configuration variables (SCPT's) is available for configuration of the frequency converter parameters. These parameters require setting
only once, usually following installation.
NB!
Please note that the settings written to configuration properties (nci's) will be stored in the non-volatile memory. Continuous writing
to configuration properties may damage the non-volatile memory.
5.4 Net w or k Var iable Descr ipt ion - VSD Pr ofile - input
5.4.1 Fr equency Conver t er Speed Set point
Var iable nam e:
nviDrvSpeedStpt
This input variable provides start / stop control and a speed reference.
Var iable nam e
nciMaxSpeed
nciMinSpeed
nciNmlSpeed
nciNmlFreq
nciRampUpTime
nciRampDownTime
nciSndHrtBt
SNVT t ype: St at e:
SNVT_switch 0 (False)
1 (True)
1 (True)
1 (True)
0xFF (default)
®
MG.11.E2.02 - VLT is a registered Danfoss trademark
5 Configuration of the system
SNVT t ype Profile
SNVT_lev_percent VSD 6010
SNVT_lev_percent VSD 6010
SNVT_rpm VSD 6010
SNVT_freq_hz VSD 6010
SNVT_time_sec VSD 6010
SNVT_time_sec VSD 6010
SNVT_time_sec VSD 6010
Value: Com m and:
Any Stop
0 Running 0 %
1-200 Running 0.5 to 100 %
201-255 Running 100 %
Any AUTO (invalid, no action)
FC 100 pa-
ram et er
4-13
4-11
1-25
1-23
3-41
3-42
-
5
