VLT® FC 100 LonWorks
5.2.2 Net w ork var iable descript ion - FC VSD Pr of ile - out put
St at us Word
Var iable nam e:
nvoStatusWord
This variable is a 16-bit word providing status information on the frequency converter. For more information on the status word, please refer to the
Danfoss FC Control Profile
section.
NB!
Please note that in the representation of the Status Word in the LonMaker Browser, the Least Significant Bit (LSB) is to the far left.
Dr ive Out put [ % ]
Var iable SNVT
nam e: t ype:
nvoOutputPcnt SNVT_lev_percent
In open loop operation, this variable contains the frequency converter output frequency in percentage, within the reference range.
In closed loop operation, this variable contains the frequency converter feedback signal, within the reference range.
Dr ive Out put [ Hz]
Var iable SNVT
nam e: t ype:
nvoOutputHz SNVT_freq_hz
This variable displays the actual output of the frequency converter motor frequency in Hz.
k Wh Count er [ k Wh]
Var iable SNVT
nam e: t ype:
nvoDrvEnrg SNVT_elec_kwh_l
This variable contains the power consumption of the motor in kWh measured as a mean value over a one hour period.
SNVT t ype:
SNVT_state
-163.840 %
Min.
0 Hz
Min.
0 kWh
®
MG.11.E2.02 - VLT is a registered Danfoss trademark
St at e:
Boolean 1 bit x 16
Value:
Min. Max .
+163.840 %
Value:
Max .
6,500 Hz
Value:
Max.
219,748,364.8 kWh
5 Configuration of the system
Resolut ion:
0.005 %
Resolut ion:
1 Hz
Resolut ion:
1 kWh
