VLT® FC 100 LonWorks

5 Conf igur at ion of t he syst em

5.1 Conf igur ing t he Syst em
5.1.1 How t o Configur e t he LonWor k s Net w or k
The LonWorks option card contains a Neuron chip with a unique address. This Neuron ID is a 48 bit number that identifies each Neuron chip manufactured.
Addressing nodes on the LonWorks network is performed at the time of installation using an installation tool or network management tool (e.g. LonMaker).
Addressing requires the retrieval of the Neuron ID for the node.
There are several methods by which the network software can retrieve the Neuron ID and address the node:
1. Service Pin – The push-button service switch sends the Neuron ID over the network.
If the network software prompts the action, press the Service Pin switch (O400) to transmit the Neuron ID over the network. Please refer to
the How to Install section for the location of the Service Pin switch.
2. Quer y and Wink - Upon receiving a Wink command, both LED's flashes (½ Hz for 20 sec.) so the installer can locate the node. The option
sends out its Neuron ID over the network in response to the query command.
3. Neur on I D Label – The installer can manually enter the Neuron ID during installation. The Neuron ID can be found on the label of the option
in text and barcode.
Resour ce Files
A LonMark interface file (.XIF file extension) provides the host processor with device information. Using this file it is possible to design a LonWorks network
without the adjustable frequency converter being physically present. Other resource files are:
• Type file (.typ file extension)
• Format file (.fmt file extension)
• Language description file (.eng, .enu and other file extensions)
The resource files can be downloaded from the web site
Here you will also find a free download of an LNS plug-in for the use in the LonMaker tool.
5.1.2 Funct ional Pr of iles
LonMark functional profiles are used to describe in detail the application layer interface, including the network variables, configuration properties, and
commonly used control functions.
www.danfoss.com/BusinessAreas/DrivesSolution
®
MG.11.E2.02 - VLT is a registered Danfoss trademark
