5 Configuration of the system
Analog I nput ( X42/ 1)
Variable
nam e:
nvo109AnIn1
Analog I nput ( X42/ 3)
Variable
nam e:
5
nvo109AnIn2
Analog I nput ( X42/ 5)
Variable
nam e:
nvo109AnIn3
These variables contain the value allocated to the analog input terminal X42/1-5 of the
the commissioning tool.
NB!
This variable is available only if the Analog I/O option (MCB109) has been installed.
32
SNVT
t ype:
Changeable
SNVT_volt
SNVT_temp_p
SNVT_lev_percent
SNVT
t ype:
Changeable
SNVT_volt
SNVT_temp_p
SNVT_lev_percent
SNVT
t ype:
Changeable
SNVT_volt
SNVT_temp_p
SNVT_lev_percent
MG.11.E2.02 - VLT
Value:
Min.
Max .
0 V
10 V
-273.15 °C
327.66 °C
0 %
100 %
Value:
Min.
Max .
0 V
10 V
-273.15 °C
327.66 °C
0 %
100 %
Value:
Min.
Max .
0 V
10 V
-273.15 °C
327.66 °C
0 %
100 %
Analog I/O option, MCB109
®
is a registered Danfoss trademark
VLT® FC 100 LonWorks
Resolut ion:
0.1 V
0.01 °C
0,1 %
Resolut ion:
0.1 V
0.01 °C
0,1 %
Resolut ion:
0.1 V
0.01 °C
0,1 %
. The variable type is changeable with
