5 Configuration of the system
5.2 Net w or k Var iable Descr ipt ion
5.2.1 - FC VSD Pr of ile - input
St art / St op
Variable
nam e:
nviStartStop
5
This variable sends a Start or Stop command to the frequency converter and a reference (0 - 100 %)
NB!
The reference value of nviStartStop will only be valid
if both nviRefPcnt and nviRefHz are = 0
Cont rol Word
Variable
nam e:
nviControlword
The input network variable nviControlWord is a 16-bit word providing additional operational control of the frequency converter.
For more information about the Control word, please refer to the
NB!
Please note in the representation of the Control Word in the LonMaker Browser, the LSB is to the far left.
Reset f ault
Variable
nam e:
nviResetFault
This variable sends a reset command to the frequency converter via bit 7 in the Control Word (0x04BC), see the
22
SNVT
St at e:
t ype:
SNVT_switch 0 (False)
1 (True)
1 (True)
1 (True)
0xFF (default)
SNVT
t ype:
SNVT_state
Danfoss FC Control Profile
SNVT
St at e:
t ype:
SNVT_switch 0 (False)
1 (True)
0xFF (default)
MG.11.E2.02 - VLT
Value:
Any
0
1-200
201-255
Any
Boolean 1 bit x 16
section.
Value:
Any
Any
Any AUTO (invalid, no action)
Danfoss FC Control Profile
®
is a registered Danfoss trademark
VLT® FC 100 LonWorks
Com m and:
Stop (0x043C)
Running 0% (0x047C)
Running 0.5 to 100.0%
Running100%
AUTO (invalid, no action)
St at e:
Com m and:
No reset
Reset (0x04B)
section.
