This chapter contains general information and detailed specifications of the ICO520. The
Chapter 1 includes the following sections:
◼

General Description

◼ System Specification
◼
Dimensions
◼ I/O Outlets
1.1 General Description
The fanless embedded system ICO520 is an industrial-grade gateway with a robust hardware
design, an ideal solution for communications control and protocol converter applications in
harsh environments. Designed for operation in strict conditions, the ICO520 adopts a low
power consumption Intel Alder Lake-P i7/ i5/ i3/ Celeron processor, supporting industrial
operating temperature range from -40°C to +50°C. The ICO520 offers a wide selection of I/O
functions, including 4 x USB, 2 x HDMI, 4 x 2.5GbE LAN, 16-bit isolated DIO and 4 x
isolated COM design. Its size makes it suitable for DIN rail or wall mount, allowing users
to easily put it into a control cabinet. Compatible with Windows® 10/11 and Linux, the ICO520
provides programmers with a friendly environment for developing application software at a
lower cost. There two kinds of categories for ICO520, one is Fully type and the other one is
Simplified type. The main difference between Fully type and Simplified type is I/O extensible
capabilities.
Fully Type
The ICO520 adopts an advanced cooling system and supports the 2.5" SATA drive, mSATA
and M.2 NVMe (2242, 2280), making it a perfect field control & edge computer solution for the
following markets:
◼
Utility industries (water; energy; chemical plant; mining...)
◼ Public transportation industries (traffic/highway control; train wayside control...)
◼ Homeland security (weather monitoring/alarm system...)
Introduction
ICO520 Series User's Manual
SECTION 1
INTRODUCTION
Simplified Type
1
