1.2.19

Dimensions

82mm(3.42") (W) x135mm(5.31") (D) x155mm(6.1") (H)
⚫
1.2.20

System I/O Outlets

⚫ Two HDMI connector display.
⚫ Four 10/100/1000/2500 base-T RJ-45 connectors with 1.5KV magnetic isolated protection.
⚫ Four USB 3.1 connectors.
⚫ Two 2x6-pin terminal block connectors for DIO.
⚫ Four Terminal Block connector for COM.
⚫ One DC power input with 3-pin terminal block.
⚫
Five antenna holes.
⚫ Three external SIM slots.
1.2.21

Check list

Fully Type
⚫ ICO520 System Unit x 1
⚫ Din-rail Kit x 1
⚫ Terminal block(3x1pin) of Power x1
⚫
Terminal block(6x2pin) of DIO x2
⚫ Terminal block(2x5pin) of COM x 2
⚫ DDR Thermal Pad x 1 and Breaket for DDR Thermal Pad x 1
⚫
M.2 KeyB Thermal Pad x 1 and Breaket for M.2 KeyB Thermal Pad x 1
⚫ SSD Tray x 1
Screws for 2.5" SATA SSD x 4
⚫
Screws(M3*6L) for 2.5" SATA SSD Tray x 4
⚫
⚫
Screws(M2*5L) for Mini Card x 2 and screws(M3*3L) for M.2 x 1
⚫ Breaket for HDMI x 2
Simplified Type
⚫ ICO520 System Unit x 1
⚫ Din-rail Kit x 1
⚫ Terminal block(3x1pin) of Power x1
⚫
DDR Thermal Pad x 1 and Breaket for DDR Thermal Pad x 1
⚫ M.2 KeyB Thermal Pad x 1 and Breaket for M.2 KeyB Thermal Pad x 1
⚫ SSD Tray x 1
Screws for 2.5" SATA SSD x 4
⚫
Screws(M3*6L) for 2.5" SATA SSD Tray x
⚫
⚫ Screws(M2*5L) for Mini Card x 2 and screws(M3*3L) for M.2 x 1
⚫ Breaket for HDMI x 2
