ICO520 Series User's Manual
Type)
⚫ Features(Fully
◼ Fanless design
◼ Wide temperature operation:
▪ with i7-1265UE and i5-1245UE: -40°C ~ +50°C
with i3-1215UE and Celeron 7305E: -40°C ~ +60°C
▪
◼ Supports 4 RJ-45 2.5Gb Ethernet ports
◼
Supports dual display, 2 HDMI ports
◼ 4 USB3.1 ports
◼
6 LED indicators (power, SSD, 4 x programmable)
◼ I/O window for mini card expansion
▪ 1 x M.2 Key B 3050/3052 slot: PCIe/USB (for 5G/Wi-Fi)
▪ 1 x Full-size Rev.1.2 PCI Express Mini Card slot: PCIe/USB (for LTE/Wi-Fi)
▪ 1 x Full-size Rev.1.2 PCI Express Mini Card slot: USB/SATA (for Wi-Fi/mSATA)
▪
3 x SIM slot (1 for M.2; 2 for full-size PCI Express Mini Card)
▪ 1 x M.2 (PCIe Gen4 x4): NVMe (2242/2280) (optional, only for Fully Type)
◼
Supports one 2.5" SATA SSD and one full-size mSATA
◼ Module for I/O expansion:
▪ 8-pin isolated Digital Input ports (source type)
▪ 8-pin isolated Digital Output ports (sink type)
▪ 4 isolated COM ports with 4-wire and phoniex type, supporting RS-232/422/485
▪ one M.2 (PCIe Gen2x4) NVMe (2242, 2280)
◼ Wide range 12 ~ 24V DC-in with terminal block, supporting OVP, UVP, OCP, RPP
◼ Din-Rail mounting (default) and wall mounting (optional)
◼ Passed CE, FCC and UKCA testing
Simplified Type)
⚫ Features(
◼ Fanless design
◼ Wide temperature operation:
▪
with i7-1265UE and i5-1245UE: -40°C ~ +50°C
with i3-1215UE and Celeron 7305E: -40°C ~ +60°C
▪
◼ Supports 4 RJ-45 2.5Gb Ethernet ports
◼ Supports dual display, 2 HDMI ports
◼ 4 USB3.1 ports
◼ 6 LED indicators (power, SSD, 4 x programmable)
◼ I/O window for mini card expansion
▪ 1 x M.2 Key B 3050/3052 slot: PCIe/USB (for 5G/Wi-Fi)
▪ 1 x Full-size Rev.1.2 PCI Express Mini Card slot: PCIe/USB (for LTE/Wi-Fi)
▪ 1 x Full-size Rev.1.2 PCI Express Mini Card slot: USB/SATA (for Wi-Fi/mSATA)
▪
3 x SIM slot (1 for M.2; 2 for full-size PCI Express Mini Card)
◼ Supports one 2.5" SATA SSD and one full-size mSATA
◼ Wide range 12 ~ 24V DC-in with terminal block, supporting OVP, UVP, OCP, RPP
◼ Din-Rail mounting (default) and wall mounting (optional)
◼ Passed CE, FCC and UKCA testing
