- Page 1 Products Solutions Services BA02086D/06/EN/02.24-00 71645356 2024-05-15 Valid as of version 01.01.zz (Device firmware) Operating Instructions Proline Prosonic Flow W 400 Ultrasonic time-of-flight flowmeter HART...
- Page 2 • The manufacturer reserves the right to modify technical data without prior notice. Your Endress+Hauser sales organization will supply you with current information and updates to this manual. Endress+Hauser...
-
Page 3: Table Of Contents
Proline Prosonic Flow W 400 HART Table of contents Table of contents 6.1.3 Environmental and process About this document ....6 requirements .... - Page 4 10.7.2 Write protection via write protection 13.3 Endress+Hauser services ....148 switch ..... . . 117 Repair .
- Page 5 14.2 Spare parts ......149 14.3 Endress+Hauser services ....149 14.4 Return .
-
Page 6: About This Document
About this document Proline Prosonic Flow W 400 HART About this document Document function These Operating Instructions contain all the information required in the various life cycle phases of the device: from product identification, incoming acceptance and storage, to installation, connection, operation and commissioning, through to troubleshooting, maintenance and disposal. -
Page 7: Tool Symbols
Proline Prosonic Flow W 400 HART About this document Symbol Meaning Light emitting diode is on. Light emitting diode is flashing. 1.2.4 Tool symbols Symbol Meaning Torx screwdriver Phillips head screwdriver Open-ended wrench 1.2.5 Symbols for certain types of information... -
Page 8: Documentation
• Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. The following documentation may be available depending on the device version ordered: Document type... -
Page 9: Safety Instructions
Proline Prosonic Flow W 400 HART Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. -
Page 10: Workplace Safety
Safety instructions Proline Prosonic Flow W 400 HART Workplace safety When working on and with the device: ‣ Wear the required personal protective equipment as per national regulations. Operational safety Damage to the device! ‣ Operate the device in proper technical condition and fail-safe condition only. -
Page 11: Protecting Access Via Hardware Write Protection
Proline Prosonic Flow W 400 HART Safety instructions Function/interface Factory setting Recommendation WLAN Enabled On an individual basis following risk (order option in display module) assessment WLAN security mode Enabled (WPA2- Do not change PSK) WLAN passphrase Serial number Assign an individual WLAN passphrase during (Password) →... -
Page 12: Access Via Web Server
Safety instructions Proline Prosonic Flow W 400 HART General notes on the use of passwords • The access code and network key supplied with the device should be changed during commissioning for safety reasons. • Follow the general rules for generating a secure password when defining and managing the access code and network key. -
Page 13: Product Description
Proline Prosonic Flow W 400 HART Product description Product description The measuring system consists of a transmitter and one or two sensor sets. The transmitter and sensor sets are mounted in physically separate locations. They are interconnected by sensor cables. -
Page 14: Product Design
Product description Proline Prosonic Flow W 400 HART Product design A0045030 1 Important components Display module Intelligent sensor electronics module HistoROM DAT (plug-in memory) Main electronics module Terminals (screw terminals, some available as plug-in terminals) or fieldbus connectors Transmitter housing... -
Page 15: Incoming Acceptance And Product
Is the envelope present with accompanying documents? • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • The Technical Documentation is available via the Internet or via the Endress+Hauser Operations app: Product identification→ 16. -
Page 16: Transmitter Nameplate
• The "Additional standard device documentation" and "Supplementary device-dependent documentation" sections • The Device Viewer: Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations app: Enter the serial number from the nameplate or scan the DataMatrix code on the nameplate. 4.2.1 Transmitter nameplate... -
Page 17: Symbols On The Device
Proline Prosonic Flow W 400 HART Incoming acceptance and product identification A0043305 4 Example of sensor nameplate, "back" CE mark, RCM mark, approval information on explosion protection and degree of protection Order code The measuring device is reordered using the order code. -
Page 18: Storage And Transport
Storage and transport Proline Prosonic Flow W 400 HART Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Protect from direct sunlight. Avoid unacceptably high surface temperatures. -
Page 19: Mounting Procedure
Proline Prosonic Flow W 400 HART Mounting procedure Mounting procedure Mounting requirements 6.1.1 Mounting position Mounting location A0042039 To prevent measuring errors arising from accumulation of gas bubbles in the measuring pipe, avoid the following mounting locations in the piping: •... - Page 20 Mounting procedure Proline Prosonic Flow W 400 HART Orientation A0045280 5 Orientation views Channel 1 upstream Channel 1 downstream Channel 2 upstream Channel 2 downstream Recommended orientation with upward flow direction Non-recommended installation range with horizontal orientation (60°) Recommended installation range max. 120°...
- Page 21 Proline Prosonic Flow W 400 HART Mounting procedure 2 × DN 2 × DN 2 × DN 2 × DN 0…15 × DN 0…15 × DN 0…15 × DN A0053788 Inlet and outlet runs DN 50 to 4000 (2 to 160") Inlet and outlet runs DN 15 to 65 (½...
- Page 22 Mounting procedure Proline Prosonic Flow W 400 HART 3× DN 15 × DN 10 × DN 20 × DN 0…15 × DN 20 × DN 15 × DN 0…15 × DN 15 × DN A0053787 Inlet and outlet runs DN 50 to 4000 (2 to 160") Inlet and outlet runs DN 15 to 65 (½...
- Page 23 Proline Prosonic Flow W 400 HART Mounting procedure The measured values of both sensor sets are averaged. Configuration of the measurement is only performed once and is adopted for both measuring paths. If extending the measuring point from single-path measurement to two-path measurement, a sensor of the same design must be selected.
-
Page 24: Sensor Set Selection And Arrangement
Mounting procedure Proline Prosonic Flow W 400 HART Installation dimensions For the dimensions and installation lengths of the device, see the "Technical Information" document, "Mechanical construction" section 6.1.2 Sensor set selection and arrangement If mounting horizontally, always mount the sensor set so that it is offset at an angle of ±30°... - Page 25 Proline Prosonic Flow W 400 HART Mounting procedure Two-path measurement (2 sensor sets) Vertical mounting A0042016 A0042017 11 1 traverse 12 2 traverses Horizontal mounting 120° 120° 120° 120° A0046760 A0044304 13 1 traverse 14 2 traverses Operating frequency selection The sensors of the measuring device are available with adapted operating frequencies.
- Page 26 Mounting procedure Proline Prosonic Flow W 400 HART Measuring pipe material: steel, cast iron Kinematic viscosity cSt [mm 0 < v ≤ 10 10 < v ≤ 100 100 < v ≤ 1000 Measuring pipe wall thickness [mm (in)] Converter frequency (sensor version/number of traverses) 1.0 to 1.9 (0.04 to 0.07)
-
Page 27: Environmental And Process Requirements
Proline Prosonic Flow W 400 HART Mounting procedure Measuring pipe material: glass-fiber reinforced plastic Kinematic viscosity cSt [mm 0 < v ≤ 10 10 < v ≤ 100 100 < v ≤ 1000 Nominal diameter [mm (")] Converter frequency (sensor version/number of traverses) 15 to 50 (¹⁄₂... -
Page 28: Special Mounting Instructions
Mounting procedure Proline Prosonic Flow W 400 HART Medium pressure range No pressure limitation For correct measurement, the static pressure of the medium must be higher than the vapor pressure. 6.1.4 Special mounting instructions Display guard ‣ To ensure that the display guard can be easily opened, maintain the following minimum head clearance: 350 mm (13.8 in) -
Page 29: Mounting The Sensor
Proline Prosonic Flow W 400 HART Mounting procedure 6.2.3 Mounting the sensor WARNING Risk of injury when mounting sensors and strapping bands! ‣ Suitable gloves and goggles must be worn due to the increased risk of cuts. Sensor configuration and settings DN 15 to 65 (½... - Page 30 Mounting procedure Proline Prosonic Flow W 400 HART CAUTION Damage to the plastic, copper or glass pipes due to overtightening the nuts of the U- shaped screws! ‣ The use of a metal half-shell (on the opposite side of the sensor) is recommended for plastic, copper or glass pipes.
- Page 31 Proline Prosonic Flow W 400 HART Mounting procedure 7. Push down the tensioning screw and tighten the strapping bands so they cannot slip. A0043372 18 Tighten the tensioning screws of the strapping bands. 8. If necessary, shorten the strapping bands and trim the cut edges.
- Page 32 Mounting procedure Proline Prosonic Flow W 400 HART A0043373 19 Holder with strapping bands (medium nominal diameters), with hinged screw Mounting bolts Strapping band Tensioning screw A0044350 20 Holder with strapping bands (medium nominal diameters), without hinged screw...
- Page 33 Proline Prosonic Flow W 400 HART Mounting procedure 3. Select the mounting location of the sensors with the given sensor distance and optimum inlet run conditions,. In doing so, ensure there is nothing impeding sensor mounting over the entire circumference of the measuring pipe.
- Page 34 Mounting procedure Proline Prosonic Flow W 400 HART A0043374 21 Holder with strapping bands (large nominal diameters) Strap bolt with guide* Strapping band* Tensioning screw *The distance between the strap bolts and strapping band lock must be at least 500 mm (20 in).
- Page 35 Proline Prosonic Flow W 400 HART Mounting procedure 13 mm A0043375 22 Holder with welded bolts Welding seam Locking nut Hole diameter max. 8.7 mm (0.34 in) Installing sensor – small nominal diameters DN 15 to 65 (½ to 2½") Requirements •...
- Page 36 Mounting procedure Proline Prosonic Flow W 400 HART 3. Position the sensor housing on the sensor holder. A0043377 24 Positioning the sensor housing 4. Attach the sensor housing to the sensor holder by locking the bracket into place.
- Page 37 Proline Prosonic Flow W 400 HART Mounting procedure Material The following material is required for mounting: • Two strapping bands incl. mounting bolts and centering plates where necessary (already pre-assembled → 31, → 32) • Two measuring wires, each with a cable lug and a fixer to fix the strapping bands •...
- Page 38 Mounting procedure Proline Prosonic Flow W 400 HART Procedure with a tape measure: 1. Use a tape measure to determine the pipe diameter d. 2. Mount the opposite mounting bolt at d/2 from the front mounting bolt. The distance must be d/2 = d' / 2 on both sides.
- Page 39 Proline Prosonic Flow W 400 HART Mounting procedure 4. Fit the sensor cover on the sensor holder and turn until the sensor cover engages with a click and the arrows (▴ / ▾ "close") are pointing towards one another. 5. Insert the sensor cable into each individual sensor until the end stop.
- Page 40 Mounting procedure Proline Prosonic Flow W 400 HART Procedure: 1. Position the strapping bands using the mounting rail [only DN50 to 600 (2 to 24"), for larger nominal diameters, measure the distance between the center of the strap bolts directly]: Fit the mounting rail with the bore identified by the letter (from the Result sensor distance / measuring aid parameter) over the mounting bolt of strapping band 1 that is fixed in place.
-
Page 41: Mounting The Transmitter
Proline Prosonic Flow W 400 HART Mounting procedure 8. Insert the sensor cable into each individual sensor until the end stop and tighten the locking nut. A0043386 34 Mounting the sensors and connecting the sensor cables This completes the mounting procedure. The sensors can now be connected to the transmitter via the sensor cables and the error message can be checked in the sensor check function. - Page 42 Mounting procedure Proline Prosonic Flow W 400 HART Wall mounting 17 (0.67) 14 (0.55) 5.8 (0.23) 5.8 (0.23) 149 (5.85) A0020523 35 Unit mm (in) 1. Drill the holes. 2. Insert wall plugs into the drilled holes. 3. Lightly screw in the securing screws.
-
Page 43: Turning The Display Module
Proline Prosonic Flow W 400 HART Mounting procedure 6.2.5 Turning the display module The display module can be turned to optimize display readability and operability. TX 20 A0046804 1. Loosen the fixing screws of the housing cover. 2. Open the housing cover. - Page 44 Mounting procedure Proline Prosonic Flow W 400 HART Are the securing screw and securing clamp tightened securely? Is the sensor holder properly grounded (in the event of different potential between the sensor holder and transmitter)? Endress+Hauser...
-
Page 45: Electrical Connection
Proline Prosonic Flow W 400 HART Electrical connection Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage. -
Page 46: Terminal Assignment
Electrical connection Proline Prosonic Flow W 400 HART Connecting cable between the transmitter and sensor Sensor cable for sensor - transmitter A0044949 Standard cable • TPE: -40 to +80 °C (-40 to +176 °F) • TPE halogen-free: -40 to +80 °C (-40 to +176 °F) •... -
Page 47: Preparing The Measuring Device
Proline Prosonic Flow W 400 HART Electrical connection Signal transmission current output 0 to 20 mA/4 to 20 mA HART and additional outputs and inputs Order code for Terminal numbers "Output" and Output 1 Output 2 Output 3 Input "Input"... - Page 48 Electrical connection Proline Prosonic Flow W 400 HART The following sequence of steps is recommended when connecting: 1. Mount the sensor and transmitter. 2. Connect the sensor cable. 3. Connect the transmitter. Connecting the sensor cable to the transmitter T 20...
-
Page 49: Connecting The Transmitter
Proline Prosonic Flow W 400 HART Electrical connection 7.3.2 Connecting the transmitter WARNING Housing degree of protection may be voided due to insufficient sealing of the housing. ‣ Screw in the screw without using any lubricant. The threads on the cover are coated with a dry lubricant. -
Page 50: Potential Equalization
Electrical connection Proline Prosonic Flow W 400 HART WARNING Housing degree of protection may be voided due to insufficient sealing of the housing. ‣ Screw in the screw without using any lubricant. Tighten the 4 fixing screws on the housing cover. - Page 51 Proline Prosonic Flow W 400 HART Electrical connection Pulse/frequency output 12345 A0028761 40 Connection example for pulse/frequency output (passive) Automation system with pulse/frequency input (e.g. PLC with 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values → 155...
-
Page 52: Ensuring The Degree Of Protection
Electrical connection Proline Prosonic Flow W 400 HART Ensuring the degree of protection 7.5.1 Degree of protection IP66/67, Type 4X enclosure The measuring device fulfills all the requirements for the degree of protection IP66/67, Type 4X enclosure. To guarantee the degree of protection IP66/67, Type 4X enclosure, carry out the following steps after electrical connection: 1. -
Page 53: Operation Options
Proline Prosonic Flow W 400 HART Operation options Operation options Overview of operation methods A0046477 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Communicator 475... -
Page 54: Structure And Function Of The Operating Menu
Operation options Proline Prosonic Flow W 400 HART Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: see the "Description of Device Parameters" document supplied with the device → 172... -
Page 55: Operating Philosophy
Proline Prosonic Flow W 400 HART Operation options 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (e.g. operator, maintenance etc.). Each user role contains typical tasks within the device life cycle. Menu/parameter... -
Page 56: Access To Operating Menu Via Local Display
Operation options Proline Prosonic Flow W 400 HART Access to operating menu via local display 8.3.1 Operational display X X X X X X X 1120.50 A0029346 Operational display Device tag → 84 Status area Display range for measured values (up to 4 lines) Operating elements →... - Page 57 Proline Prosonic Flow W 400 HART Operation options Flow velocity Signal to noise ratio Signal strength The number and display format of the measured variables can be configured via the Format display parameter (→ 101). Totalizer Symbol Meaning Totalizer ...
-
Page 58: Navigation View
Operation options Proline Prosonic Flow W 400 HART 8.3.2 Navigation view In the submenu In the wizard /../Operation 0091-1 /../Curr. output 1 Access stat.disp Assign curr. Operator Volume flow Locking status Display A0013993-EN A0016327-EN Navigation view Navigation path to current position... -
Page 59: Editing View
Proline Prosonic Flow W 400 HART Operation options Setup Is displayed: • In the menu next to the "Setup" selection • At the left in the navigation path in the Setup menu Diagnosis Is displayed: • In the menu next to the "Diagnostics" selection •... - Page 60 Operation options Proline Prosonic Flow W 400 HART Input screen The following input symbols are available in the input mask of the numeric and text editor: Numeric editor Symbol Meaning Selection of numbers from 0 to 9 … Inserts a decimal separator at the cursor position.
-
Page 61: Operating Elements
Proline Prosonic Flow W 400 HART Operation options Moves the input position one position to the right. Moves the input position one position to the left. Deletes one character immediately to the left of the input position. 8.3.4 Operating elements... -
Page 62: Opening The Context Menu
Operation options Proline Prosonic Flow W 400 HART 8.3.5 Opening the context menu Using the context menu, the user can call up the following menus quickly and directly from the operational display: • Setup • Simulation Calling up and closing the context menu The user is in the operational display. -
Page 63: Navigating And Selecting From List
Proline Prosonic Flow W 400 HART Operation options 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus. -
Page 64: Calling Up Help Text
Operation options Proline Prosonic Flow W 400 HART The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter. -
Page 65: Changing The Parameters
Proline Prosonic Flow W 400 HART Operation options 8.3.9 Changing the parameters For a description of the editing view - consisting of the text editor and numeric editor - with symbols → 59, for a description of the operating elements → 61 Example: Changing the tag name in the "Tag description"... -
Page 66: User Roles And Related Access Authorization
Operation options Proline Prosonic Flow W 400 HART Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN 8.3.10 User roles and related access authorization The two user roles "Operator" and "Maintenance" have different write access to the parameters if the customer defines a user-specific access code. -
Page 67: Enabling And Disabling The Keypad Lock
Proline Prosonic Flow W 400 HART Operation options 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation. As a result, it is no longer possible to navigate through the operating menu or change the values of individual parameters. -
Page 68: Requirements
Operation options Proline Prosonic Flow W 400 HART 8.4.2 Requirements Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have a RJ45 The operating unit must have a WLAN interface. interface. Connection Standard Ethernet cable Connection via Wireless LAN. -
Page 69: Connecting The Device
Proline Prosonic Flow W 400 HART Operation options Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON For information on enabling the Web server → 73... - Page 70 Operation options Proline Prosonic Flow W 400 HART NOTICE Note the following to avoid a network conflict: ‣ Avoid accessing the measuring device simultaneously from the same mobile terminal via the service interface (CDI-RJ45) and the WLAN interface. ‣ Only activate one service interface (CDI-RJ45 or WLAN interface).
-
Page 71: Logging On
Proline Prosonic Flow W 400 HART Operation options 2. Enter the IP address of the web server in the address line of the web browser: 192.168.1.212 The login page appears. 2 3 4 Device name: Device tag: Signal Status:... -
Page 72: User Interface
Operation options Proline Prosonic Flow W 400 HART 8.4.5 User interface A0029418 Function row Local display language Navigation area Header The following information appears in the header: • Device name • Device tag • Device status with status signal → 135 •... -
Page 73: Disabling The Web Server
Proline Prosonic Flow W 400 HART Operation options Working area Depending on the selected function and the related submenus, various actions can be performed in this area: • Configuring parameters • Reading measured values • Calling up help text • Starting an upload/download 8.4.6... -
Page 74: Connecting The Operating Tool
Operation options Proline Prosonic Flow W 400 HART 8.5.1 Connecting the operating tool Via HART protocol This communication interface is available in device versions with a HART output. A0028747 45 Options for remote operation via HART protocol Control system (e.g. PLC) Field Communicator 475 Computer with operating tool (e.g. - Page 75 Proline Prosonic Flow W 400 HART Operation options A0043149 Transmitter with integrated WLAN antenna LED lit constantly: WLAN reception is enabled on measuring device LED flashing: WLAN connection established between operating unit and measuring device Computer with WLAN interface and web browser (e.g. Microsoft Internet Explorer, Microsoft Edge) for accessing the integrated device web server or with operating tool (e.g.
-
Page 76: Fieldcare
FieldCare Function range FDT-based (Field Device Technology) plant asset management tool from Endress+Hauser. It can configure all smart field units in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition. -
Page 77: Devicecare
DeviceCare Function range Tool for connecting and configuring Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. Innovation brochure IN01047S Source for device description files →... -
Page 78: Ams Device Manager
Operation options Proline Prosonic Flow W 400 HART Field Xpert SMT77 The Field Xpert SMT77 tablet PC for device configuration enables mobile plant asset management in areas categorized as Ex Zone 1. • Technical Information TI01418S • Operating Instructions BA01923S •... -
Page 79: System Integration
Proline Prosonic Flow W 400 HART System integration System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.00.zz • On the title page of the manual • On the transmitter nameplate • Firmware version Diagnostics →... - Page 80 System integration Proline Prosonic Flow W 400 HART Dynamic variables Measured variables (HART device variables) Primary dynamic variable (PV) Volume flow Secondary dynamic variable (SV) Totalizer 1 Tertiary dynamic variable (TV) Totalizer 2 Quaternary dynamic variable (QV) Totalizer 3 The assignment of the measured variables to the dynamic variables can be modified and...
-
Page 81: Other Settings
Proline Prosonic Flow W 400 HART System integration Other settings Burst mode functionality in accordance with HART 7 Specification: Navigation "Expert" menu → Communication → HART output → Burst configuration → Burst configuration 1 to n ‣ Burst configuration 1 to n Burst mode 1 to n →... - Page 82 System integration Proline Prosonic Flow W 400 HART Parameter Description Selection / User entry Burst variable 0 For HART command 9 and 33: select the HART device variable • Not used or the process variable. • Volume flow • Mass flow • Flow velocity •...
-
Page 83: Commissioning
Proline Prosonic Flow W 400 HART Commissioning Commissioning 10.1 Post-mounting and post-connection check Before commissioning the device: ‣ Make sure that the post-installation and post-connection checks have been performed successfully. • Checklist for "Post-mounting" check→ 43 • Checklist for "Post-connection check" → 52 10.2... -
Page 84: Defining The Tag Name
Commissioning Proline Prosonic Flow W 400 HART X X X X X X X 20.50 Main menu Display language English Display/operat. Setup Main menu Display/operat. Setup Diagnostic / ../Setup Medium selection XXXXXXXXX XXXXXXXXX A0032222-EN 48 Navigation to "Setup" menu using the example of the local display The number of submenus and parameters can vary depending on the device version. -
Page 85: Setting The System Units
Proline Prosonic Flow W 400 HART Commissioning XXXXXXXXX A0029422 49 Header of the operational display with tag name Tag name Enter the tag name in the "FieldCare" operating tool → 77 Navigation "Setup" menu → Device tag Parameter overview with brief description... -
Page 86: Configuring The Measuring Point
Commissioning Proline Prosonic Flow W 400 HART Parameter overview with brief description Parameter Description Selection Factory setting Volume flow unit Select volume flow unit. Unit choose list Country-specific: • m³/h Result • ft³/min The selected unit applies to: • Output •... - Page 87 Proline Prosonic Flow W 400 HART Commissioning Medium → 88 → 88 Medium temperature Sound velocity → 88 Viscosity → 88 Pipe material → 88 Pipe sound velocity → 88 Pipe dimensions → 88 Pipe circumference →...
- Page 88 Commissioning Proline Prosonic Flow W 400 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Measuring point configuration – Select configuration for the • 1 measuring point Depending on the measuring point. - signal path 1 sensor version •...
- Page 89 Proline Prosonic Flow W 400 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Pipe circumference The Pipe circumference Define the pipe circumference. 30 to 62 800 mm – option is selected in the Pipe dimensions parameter. Pipe outer diameter...
-
Page 90: Checking The Installation Status
Commissioning Proline Prosonic Flow W 400 HART Parameter Prerequisite Description Selection / User Factory setting entry / User interface FlowDC inlet configuration The 1 measuring point - 2 Select FlowDC inlet • Off – signal paths option is selected configuration. • Single elbow in Measuring point •... - Page 91 Proline Prosonic Flow W 400 HART Commissioning Navigation "Setup" menu → Installation status ‣ Installation status Installation status (2958) → 91 Signal strength (2914) → 91 → 91 Signal to noise ratio (2917) Sound velocity (2915) → 91 Sound velocity deviation (2986) →...
-
Page 92: Configuring The Status Input
Commissioning Proline Prosonic Flow W 400 HART 10.4.5 Configuring the status input The Status input submenu guides the user systematically through all the parameters that have to be set for configuring the status input. The submenu only appears if the device was ordered with a status input . -
Page 93: Configuring The Current Output
Proline Prosonic Flow W 400 HART Commissioning 10.4.6 Configuring the current output The Current output wizard guides you systematically through all the parameters that have to be set for configuring the current output. Navigation "Setup" menu → Current output 1 ‣... -
Page 94: Switch Output
Commissioning Proline Prosonic Flow W 400 HART Parameter Prerequisite Description Selection / User Factory setting entry Lower range value output In Current span parameter Enter lower range value for the Signed floating-point Depends on country: (→ 93), one of the measured value range. - Page 95 Proline Prosonic Flow W 400 HART Commissioning Operating mode (0469) → 96 → 96 Assign pulse output (0460) Assign frequency output (0478) → 97 Switch output function (0481) → 99 Assign diagnostic behavior (0482) → 99 Assign limit (0483) →...
-
Page 96: Operating Mode (0469)
Commissioning Proline Prosonic Flow W 400 HART Configuring the pulse output Navigation "Setup" menu → Pulse/frequency/switch output 1 to n ‣ Pulse/frequency/switch output 1 to n Operating mode → 96 Assign pulse output → 96 Value per pulse →... -
Page 97: Minimum Frequency Value (0453)
Proline Prosonic Flow W 400 HART Commissioning Configuring the frequency output Navigation "Setup" menu → Pulse/frequency/switch output 1 to n ‣ Pulse/frequency/switch output 1 to n Operating mode → 97 Assign frequency output → 97 Minimum frequency value →... - Page 98 Commissioning Proline Prosonic Flow W 400 HART Parameter Prerequisite Description Selection / User Factory setting entry Maximum frequency value The Frequency option is Enter maximum frequency. 0.0 to 10 000 Hz – selected in the Operating mode parameter (→ 96) and a process variable is...
-
Page 99: Switch-On Value (0466)
Proline Prosonic Flow W 400 HART Commissioning Assign flow direction check → 100 Assign status → 100 → 100 Switch-on value Switch-off value → 100 Switch-on delay → 100 Switch-off delay → 100 → 100... -
Page 100: Configuring The Local Display
Commissioning Proline Prosonic Flow W 400 HART Parameter Prerequisite Description Selection / User Factory setting entry Assign flow direction check • The Switch option is Select process variable for flow – selected in the Operating direction monitoring. mode parameter. • The Flow direction check... - Page 101 Proline Prosonic Flow W 400 HART Commissioning Value 1 display → 101 0% bargraph value 1 → 101 → 101 100% bargraph value 1 Value 2 display → 101 Value 3 display → 102 0% bargraph value 3 →...
-
Page 102: Configuring The Low Flow Cut Off
Commissioning Proline Prosonic Flow W 400 HART Parameter Prerequisite Description Selection / User Factory setting entry Value 3 display A local display is provided. Select the measured value that For the picklist, see – is shown on the local display. Value 1 display parameter (→... - Page 103 Proline Prosonic Flow W 400 HART Commissioning Navigation "Setup" menu → Low flow cut off ‣ Low flow cut off Assign process variable (1837) → 103 On value low flow cutoff (1805) → 103 → 103 Off value low flow cutoff (1804)
-
Page 104: Advanced Settings
Commissioning Proline Prosonic Flow W 400 HART 10.5 Advanced settings The Advanced setup submenu with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu Display language English Display/operat. -
Page 105: Access Code
Proline Prosonic Flow W 400 HART Commissioning ‣ WLAN settings → 109 ‣ Heartbeat setup → 111 ‣ → 112 Administration 10.5.1 Using the parameter to enter the access code Navigation "Setup" menu → Advanced setup Parameter overview with brief description... - Page 106 Commissioning Proline Prosonic Flow W 400 HART Totalizer 1 to n operation mode → 106 Totalizer 1 to n failure behavior → 106 Parameter overview with brief description Parameter Prerequisite Description Selection Factory setting Assign process variable 1 to n –...
-
Page 107: Carrying Out Additional Display Configurations
Proline Prosonic Flow W 400 HART Commissioning 10.5.4 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣... - Page 108 Commissioning Proline Prosonic Flow W 400 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
-
Page 109: Wlan Configuration
Proline Prosonic Flow W 400 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Decimal places 3 A measured value is specified Select the number of decimal • x – in the Value 3 display places for the display value. - Page 110 Commissioning Proline Prosonic Flow W 400 HART Navigation "Setup" menu → Advanced setup → WLAN settings ‣ WLAN settings WLAN → 110 WLAN mode → 110 → 110 SSID name Network security → 110 Security identification →...
-
Page 111: Performing Heartbeat Basic Setup
Proline Prosonic Flow W 400 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Security identification – Select security settings and • Trusted issuer – download these settings via certificate menu Data management > • Device certificate Security > WLAN. -
Page 112: Using Parameters For Device Administration
Commissioning Proline Prosonic Flow W 400 HART Navigation "Setup" menu → Advanced setup → Heartbeat setup ‣ Heartbeat setup ‣ Heartbeat base settings → 112 "Heartbeat base settings" submenu Navigation "Setup" menu → Advanced setup → Heartbeat setup → Heartbeat base settings ‣... - Page 113 Indicates how long the device has been in operation. Days (d), hours (h), minutes (m) and seconds Reset access code Enter the code provided by Endress+Hauser Technical Support Character string comprising numbers, letters to reset the Maintenance code. and special characters ...
-
Page 114: Simulation
Commissioning Proline Prosonic Flow W 400 HART Parameter overview with brief description Parameter Description Selection Device reset Reset the device configuration - either entirely or in part - to a • Cancel defined state. • To delivery settings • Restart device •... - Page 115 Proline Prosonic Flow W 400 HART Commissioning Diagnostic event category → 115 Diagnostic event simulation → 115 Parameter overview with brief description Parameter Prerequisite Description Selection / User entry Assign simulation process variable – Select a process variable for the •...
-
Page 116: Protecting Settings From Unauthorized Access
Commissioning Proline Prosonic Flow W 400 HART 10.7 Protecting settings from unauthorized access The following options exist for protecting the configuration of the measuring device from unintentional modification after commissioning: • Write protection via access code for the local display and Web browser •... -
Page 117: Switch
Proline Prosonic Flow W 400 HART Commissioning 3. Enter the access code again in the Confirm access code parameter (→ 113) to confirm. The web browser switches to the login page. • Disabling parameter write protection via access code → 66. - Page 118 Commissioning Proline Prosonic Flow W 400 HART 2. Setting the write protection switch (WP) on the main electronics module to the ON position enables the hardware write protection. Setting the write protection switch (WP) on the main electronics module to the OFF position (factory setting) disables the hardware write protection.
-
Page 119: Operation
Proline Prosonic Flow W 400 HART Operation Operation 11.1 Reading off the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access authorization displayed in the Access status display parameter applies →... -
Page 120: Process Variables
Operation Proline Prosonic Flow W 400 HART 11.4.1 Process variables The Process variables submenu contains all the parameters needed to display the current measured values for each process variable. Navigation "Diagnostics" menu → Measured values → Process variables ‣ Process variables Volume flow →... -
Page 121: System Values
Proline Prosonic Flow W 400 HART Operation Parameter Prerequisite Description User interface Flow velocity – Displays the average flow velocity that Signed floating-point is currently calculated. number Dependency The unit is taken from: Velocity unit parameter Temperature Temperature is not entered as a fixed... -
Page 122: Output Values
Operation Proline Prosonic Flow W 400 HART Navigation "Diagnostics" menu → Measured values → Input values ‣ Input values Value status input → 122 Parameter overview with brief description Parameter Prerequisite Description User interface Value status input For the following order code: Shows the current input signal level. -
Page 123: Totalizer" Submenu
Proline Prosonic Flow W 400 HART Operation Parameter overview with brief description Parameter Prerequisite Description User interface Output current – Displays the current value currently 3.59 to 22.5 mA calculated for the current output. Measured current – Displays the current value currently 0 to 30 mA measured for the current output. -
Page 124: Performing A Totalizer Reset
Operation Proline Prosonic Flow W 400 HART 11.6 Performing a totalizer reset The totalizers are reset in the Operation submenu: • Control Totalizer • Reset all totalizers Navigation "Operation" menu → Totalizer handling ‣ Totalizer handling → 124 Control Totalizer 1 to n Preset value 1 to n →... -
Page 125: Function Range Of "Reset All Totalizers" Parameter
Proline Prosonic Flow W 400 HART Operation Options Description Preset + hold The totaling process is stopped and the totalizer is set to its defined start value from the Preset value parameter. Reset + totalize The totalizer is reset to 0 and the totaling process is restarted. - Page 126 Operation Proline Prosonic Flow W 400 HART Assign channel 2 → 126 Assign channel 3 → 126 → 126 Assign channel 4 Logging interval → 127 Clear logging data → 127 Data logging → 127 →...
- Page 127 Proline Prosonic Flow W 400 HART Operation Parameter Prerequisite Description Selection / User entry / User interface Logging interval The Extended HistoROM application Define the logging interval for data 0.1 to 3 600.0 s package is available. logging. This value defines the time interval between the individual data points in the memory.
-
Page 128: Diagnosis And Troubleshooting
Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Remedial action Local display dark and no output signals Supply voltage does not match the voltage Apply the correct supply voltage → 49. - Page 129 Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting Error Possible causes Remedial action Connection via HART protocol is not possible. Missing or incorrectly installed communication Install the communication resistor (250 Ω) resistor. correctly. Observe the maximum load → 155.
-
Page 130: Diodes
Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART 12.2 Diagnostic information via light emitting diodes 12.2.1 Transmitter Different LEDs in the transmitter provide information on the device status. A0029689 Supply voltage Device status Not used Communication Service interface (CDI) active 1. - Page 131 Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting Color Meaning Flashing red Fault Flashing red/green Start measuring device Endress+Hauser...
-
Page 132: Diagnostic Information On Local Display
Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. - Page 133 Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. • The background lighting changes to red.
-
Page 134: Calling Up Remedial Measures
Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage... -
Page 135: Calling Up Remedy Information
Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting A0031056 Status area with status signal Diagnostic information → 133 Remedial measures with service ID In addition, diagnostic events which have occurred can be shown in the Diagnostics menu: • Via parameter → 141 •... -
Page 136: Diagnostic Information In Fieldcare Or
Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART 12.5 Diagnostic information in FieldCare or DeviceCare 12.5.1 Diagnostic options Any faults detected by the measuring device are displayed on the home page of the operating tool once the connection has been established. -
Page 137: Calling Up Remedy Information
Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting 12.5.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: • On the home page Remedy information is displayed in a separate field below the diagnostics information. -
Page 138: Overview Of Diagnostic Information
Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART Available status signals Configuration as per HART 7 Specification (Condensed Status), in accordance with NAMUR NE107. Symbol Meaning Failure A device error has occurred. The measured value is no longer valid. - Page 139 Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Firmware incompatible 1. Check firmware version Alarm 2. Flash or replace electronic module Module incompatible 1.
- Page 140 Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Transmitter circuit 1. Restart device Alarm 2. Check if failure recurs 3. Replace sensor electronic module...
-
Page 141: Pending Diagnostic Events
Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Diagnostic of process Loop current 1 faulty 1. Check wiring Alarm 2. Change I/O module... -
Page 142: Diagnostics List
Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART Navigation "Diagnostics" menu Diagnostics Actual diagnostics → 142 Previous diagnostics → 142 → 142 Operating time from restart Operating time → 142 Parameter overview with brief description... -
Page 143: 12.10 Event Logbook
Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN 53 Using the example of the local display To call up the measures to rectify a diagnostic event: •... -
Page 144: 12.10.2 Filtering The Event Logbook
Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART 12.10.2 Filtering the event logbook Using the Filter options parameter you can define which category of event message is displayed in the Events list submenu. Navigation path Diagnostics → Event logbook → Filter options Filter categories •... -
Page 145: 12.11 Resetting The Measuring Device
Proline Prosonic Flow W 400 HART Diagnosis and troubleshooting Info number Info name I1622 Calibration changed I1624 All totalizers reset I1625 Write protection activated I1626 Write protection deactivated I1627 Web server: login successful I1628 Display: login successful I1629 CDI: login successful... - Page 146 Diagnosis and troubleshooting Proline Prosonic Flow W 400 HART Order code → 146 Extended order code 1 → 146 → 146 Extended order code 2 Extended order code 3 → 147 ENP version → 147 Device revision →...
-
Page 147: 12.13 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: •... -
Page 148: Maintenance
13.2 Measuring and test equipment Endress+Hauser offers a variety of measuring and testing equipment, such as Netilion or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services. -
Page 149: Repair
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory. -
Page 150: Disposal
Repair Proline Prosonic Flow W 400 HART 14.5 Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste. -
Page 151: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com. -
Page 152: For The Sensor
For intrinsically safe HART communication with FieldCare via the USB port HART Technical Information TI00404F Commubox FXA291 Connects Endress+Hauser field devices with a CDI interface (= Endress+Hauser Common Data Interface) and the USB port of a computer or laptop. Technical Information TI405C/07 HART Loop Converter... -
Page 153: Service-Specific Accessories
• As a downloadable DVD for local PC installation. Netilion lloT ecosystem: Unlock knowledge Endress+Hauser ' s Netilion lloT ecosystem enables you to optimize your plant performance, digitize workflows, share knowledge and improve collaboration. Based on decades of experience in process automation, Endress+Hauser offers the process industry an lloT ecosystem that enables you to gain useful insights from data. -
Page 154: Technical Data
The measuring device has an optional interface via which an externally measured variable (temperature) can be transmitted to the measuring device: digital input (via HART input or Modbus) Various pressure transmitters can be ordered from Endress+Hauser: see "Accessories" section → 153 Endress+Hauser... -
Page 155: Output
Proline Prosonic Flow W 400 HART Technical data HART protocol The measured values are written from the automation system to the measuring device via the HART protocol. The temperature and density measuring device must support the following protocol-specific functions: • HART protocol •... - Page 156 Technical data Proline Prosonic Flow W 400 HART Maximum pulse rate 10 000 Impulse/s Pulse value Configurable Assignable measured • Volume flow variables • Mass flow Frequency output Output frequency Configurable: 0 to 12 500 Hz Damping Configurable: 0 to 999 s...
- Page 157 Proline Prosonic Flow W 400 HART Technical data Pulse/frequency/switch output Pulse output Fault mode Choose from: • Actual value • No pulses Frequency output Fault mode Choose from: • Actual value • 0 Hz • Definable value between: 0 to 12 500 Hz...
-
Page 158: Power Supply
Technical data Proline Prosonic Flow W 400 HART Galvanic isolation The following connections are galvanically isolated from each other: • Inputs • Outputs • Power supply DN 50 to 4000 (2 to 160") and non-hazardous area: The clamp-on sensors can also be mounted on cathodically protected pipes. -
Page 159: Performance Characteristics
Proline Prosonic Flow W 400 HART Technical data Overcurrent protection The device must be operated with a dedicated circuit breaker, as it does not have an element ON/OFF switch of its own. • The circuit breaker must be easy to reach and labeled accordingly. - Page 160 Technical data Proline Prosonic Flow W 400 HART [m/s] [ft/s] A0041972 55 Example of the measurement error in a pipe with a nominal diameter DN > 200 (8") Measurement error of measuring device: 0.5% o.r. ± 3 mm/s (0.12 in/s) Measurement error due to installation conditions: typically 1.5% o.r.
- Page 161 Proline Prosonic Flow W 400 HART Technical data Example of max. measurement error (volume flow) [m/s] [ft/s] A0041973 56 Example of max. measurement error (volume flow) in % o.r. Pipe diameter < DN 100 (4") Pipe diameter ≥ DN 100 (4") Accuracy of outputs The outputs have the following base accuracy specifications.
-
Page 162: Mounting
The device is suitable for use outdoors and indoors with a relative humidity of 5 to 95 %. Operating height According to EN 61010-1 • ≤ 2 000 m (6 562 ft) • > 2 000 m (6 562 ft) with additional overvoltage protection (e.g. Endress+Hauser HAW Series) Degree of protection Transmitter •... -
Page 163: Process
Proline Prosonic Flow W 400 HART Technical data Electromagnetic • As per IEC/EN 61326 and NAMUR Recommendation 21 (NE 21) compatibility (EMC) • As per IEC/EN 61000-6-2 and IEC/EN 61000-6-4 • Complies with emission limits for industry as per EN 55011 (Class A) Details are provided in the Declaration of Conformity. - Page 164 Technical data Proline Prosonic Flow W 400 HART Transmitter • Proline 400 polycarbonate plastic: 1.2 kg (2.65 lb) • Proline 400 aluminum, coated: 6.0 kg (13.2 lb) Sensor Including mounting material • DN 15 to 65 (½ to 2½"): 1.2 kg (2.65 lb) •...
-
Page 165: 16.11 Display And User Interface
Proline Prosonic Flow W 400 HART Technical data DN 50 to 4000 (2 to 160"): • Sensor cable, TPE halogen-free • Cable sheath: TPE halogen-free • Cable plug: nickel-plated brass • Sensor cable PTFE • Cable sheath: PTFE • Cable plug: stainless steel 1.4301 (304), 1.4404 (316L) Ultrasonic transducer •... - Page 166 Technical data Proline Prosonic Flow W 400 HART Onsite operation Via display module Features: • Standard features 4-line, illuminated, graphic display; touch control • Order code for "Display; operation", option G "4-line, illuminated; touch control +WLAN" offers standard equipment features in addition to access via web browser Information about WLAN interface →...
- Page 167 Proline Prosonic Flow W 400 HART Technical data Supported operating Operating unit Interface Additional information tools Field Xpert SMT70/77/50 • All Fieldbus protocols Operating Instructions • WLAN interface BA01202S • Bluetooth Device description files: • CDI-RJ45 service Use update function of...
-
Page 168: 16.12 Certificates And Approvals
Technical data Proline Prosonic Flow W 400 HART Additional information on the data storage concept There are different types of data storage units in which device data are stored and used by the device: HistoROM backup T-DAT S-DAT Available data •... - Page 169 The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. UKCA marking The device meets the legal requirements of the applicable UK regulations (Statutory Instruments).
-
Page 170: 16.13 Application Packages
The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com. -
Page 171: 16.14 Accessories
For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. Standard documentation Brief operating instructions... - Page 172 Technical data Proline Prosonic Flow W 400 HART Description of device parameters Documentation code Measuring device HART Modbus RS485 Prosonic Flow W 400 GP01167D GP01207D Device-dependent Special documentation additional documentation Content Documentation code Radio approvals for WLAN interface for A309/A310 display module...
-
Page 173: Index
Proline Prosonic Flow W 400 HART Index Index Coupling medium Coupling pad or coupling gel ... 35, 36, 39 Access authorization to parameters Current consumption ......158 Read access . - Page 174 Index Proline Prosonic Flow W 400 HART Symbols ....... . . 6 Document function .
- Page 175 Proline Prosonic Flow W 400 HART Index Disposal ....... 150 Output signal .
- Page 176 Index Proline Prosonic Flow W 400 HART Recalibration ......148 Status signals ......132, 135 Reference operating conditions .
- Page 177 Proline Prosonic Flow W 400 HART Index Terminals ....... . 159 Text editor .
- Page 178 *71645356* 71645356 www.addresses.endress.com...
Need help?
Do you have a question about the Proline Prosonic Flow W 400 and is the answer not in the manual?
Questions and answers
